Audinate AES3 Dante AVIO Adapter  From Audinate

Network all your AES3 / EBU-Equipped Audio Gear Easily and Cost-Effectively with Dante AVIO



Retail:  $259.00

"Experience the Difference"

Lifetime Support

Free Lifetime Technical Support!
Our small team of dedicated experts is here to help the original purchaser for the lifetime of the product. Why? Because we care about building real relationships with our customers for life and stand behind every product we sell.
Contact us for up-to-date delivery estimate.
Payments as low as $17/mo.

Manufacturer's Description from Audinate

The Dante AVIO AES3/EBU Adapter supports 2 x 2 channels, with highquality XLR input and output connectorsand built-in asynchronous sample rate conversion. Use the AES3 Dante AVIO Adapters to add Dante networking to amplifiers, speaker processors, mixing consoles, video systems and more. Cost effective, compact and built for the road, the Dante AVIO family of adapters bring the modern network connectivity that every audio pro needs in their toolbox.



The Dante AVIO AES3 adapter is a complete, high performance Dante device, delivering all the automation and ease of use that have made Dante the most popular audio networking solution worldwide. The Dante AVIO AES3 adapter is automatically discovered and ready to use when connected, and no separate power supplies are required – just use a common PoE (Power over Ethernet) switch and any Dante AVIO adapter is ready to go. Network all your AES3 / EBUequipped audio gear easily and cost-effectively with Dante AVIO



 Interface with SDI video systems using AES3 audio.

 Put your AES3-compatible amplifiers and powered

speakers on your Dante audio network.

 Connect AES3-compatible DSPs to a Dante network

 Connect AES3-compatible microphone preamplifiers

to a Dante network



 Plug & play operation

 Built for the road

 Sample rates up to 96 kHz

 16, 24 and 32-bit audio support

 Synchronous sample rate conversion

 Excellent dynamic range, SNR and THD performance

 Configurable gain / attenuation

 Dante Audio over IP and AES67 RTP transport formats

 Power over Ethernet (PoE) support

 Dante Domain Manager ready



We’ve made all Dante AVIO adapters road-ready and tour-tough. Sonically welded ABS enclosures and quality hardware are used throughout, while cable assemblies are stress-tested to ensure reliable operation under grueling conditions. Toss them in your toolbox, show after show.



Dante AVIO adapters are all fully functional Dante interfaces, with all the features you’d expect from Dante audio networking. Each one delivers bit-perfect audio reproduction, super-low latency and sample-accurate synchronization across the entire network. All Dante devices automatically discover one another, and the entire system is managed by our easy-to-use Dante Controller software on any connected PC or Mac. Most importantly, every Dante device can connect to every other Dante device – no questions asked. All Dante AVIO adapters are fully compatible with Dante Domain Manager (DDM) for IT-level security and management, while AES67 is supported for connection to non-Dante networks.



We’ve worked hard to make the Dante AVIO family of products a cost-effective addition to any system or piece of gear, so that everyone can enjoy the benefits of Dante. Audio networking has never been easier to or more affordable, no matter how you choose to use it.


About Manufacturer

Audinate is the leading provider of professional digital audio networking technologies globally. Audinate's Dante platform distributes digital audio signals over computer networks, and is designed to bring the benefits of IT networking to the professional AV industry.  Using Dante-enabled products ensures interoperability between audio devices and allows end users to enjoy high quality, flexible solutions—typically with a lower total cost of ownership.


Audio channels 2 in, 2 out

Signal to Noise Ratio > 135dB

Connectors RJ45, 1 XLR-M, 1 XLR-F

Power Class 1 802.3af PoE

Asynchronous Sample Rate Conversion Yes

Sample Rates 44.1, 48, 96 kHz

Bit Depth 24

Dante Device Latency 1, 2, or 5ms (configurable using Dante Controller)

Impedance 110 Ohm balanced

Network Transport Dante Audio over IP, AES67 RTP

Part Number ADP-AES3-AU-2X2
