From Crane Song
- Analog Input
- Transformerless balanced stereo input on XLR-fm connectors. The default calibration is +20 dBu = Digital zero.
- Gain
- Gain adjust trims are on the back panel. The analog input range for 0 dbfs is adjustable form +16 to +26 dBu
- Word Clock Outputs
- 8 BNC connectors are a TTL level square wave that can be used to provide sync to other equipment. The WC outputs will be at the selected sample
- Internal Sample Rate
- 44.1KHz to 192KHz determined by front panel switch or the USB daw setting
- S/PDIF Output
- Unbalanced digital output 75 ohms RCA connector
- AES Output
- Balanced digital output 110 ohms XLR connector
- Optical Out
- toslink format, stereo
- Power
- 25 watts at 115 or 230 volts, 50 or 60 Hz.
- Fuse size
- MDL .3A for 115 volts; MDL .25A for 230 volts
- Pilot Lamp
- #7335 lamp
- Shipping Weight
- 15lbs (6.7kg)
- Depth Behind Panel
- 10 inches (25.4cm) plus user input/output connectors
