SPL Hermes Mastering Routing Matrix (Red)  From SPL

Mastering Router with dual Parallel Mix

SPL

$5,999.00

"Experience the Difference"

Sound Pure's 3-Year Warranty

Close
Our Free 3-Year Warranty!
In addition to the standard included manufacturer warranty, virtually all new products carry our exclusive, industry-leading, absolutely free, Sound Pure 3-Year Warranty, which includes PARTS & LABOR. This high-value perk is our way of providing the ultimate in added value to enhance the unique personal touch our small, dedicated team contributes to each purchase.
Learn more »

Lifetime Support

Close
Free Lifetime Technical Support!
Our small team of dedicated experts is here to help the original purchaser for the lifetime of the product. Why? Because we care about building real relationships with our customers for life and stand behind every product we sell.

Free Shipping

Close
This Product Ships Free!
Products ship from our well-located, climate- and humidity-controlled warehouse absolutely free (inside the continental USA). Low-cost international shipping options exist for most products.
Contact us for details »

No Sales Tax Outside North Carolina

Ships Quick!
Usually ships 3 - 5 business days after order processed.
Payments as low as $136/mo.

Manufacturer's Description from SPL

Hermes revolutionizes Mastering. Now it is possible to route an audio signal through up to eight dual-channel processors in any order. User definable presets allow the comparison of complex processing chains with just a flip of a button.

In addition, Hermes has two integrated parallel mix stages that work with any of the eight processors allowing for comparison of two compressors with different parallel mix settings. The parallel mix stages are stored with the processing chains.



Hermes routing is entirely passive using gas-capsuled and gold-plated high-end relays. All active electronics like the I/O stages and the Parallel Mixes use SPL's proprietary and unequaled 120V Technology.



Hermes speeds up the workflow in mastering in ways that were previously extremely difficult, and makes the most out of your existing mastering gear. Repatching to hear a simple change is a thing of the past with Hermes – you can change processor sequences on the fly, store them, and compare settings instantly. All with real switches, relays and no software application.



Features:

 ♦ Mastering router for 8 dual-channel processors

 ♦ Two Parallel Mix stages

 ♦ Create, store and compare complex processing chains

 ♦ With gain compensation

 ♦ Fast comparison of up to 4 processing chains

 ♦ Can be assigned to any device

 ♦ Fully passive routing using

 ♦ 120V Technology

 ♦ Gold-plated and gas-capsuled relays

 ♦ Label mode to enter device names







SPL

About Manufacturer

Sound Performance Labs! Full Range of Analog, Tube, and Digital rack gear with an innovative twist. With their most famous transient designer product, SPL has quickly become a household name in both the recording and live sound arenas.

Specifications

Inputs:

Max. Input Level: +32,5 dBu

Max. Input Level (Parallel Mix, Gain active): +28 dBu

Input Impedance: 20 kOhm (bal.)



Outputs (Speaker Output):

Max. Output Level: +32,5 dBu

Output Impedance: ‹ 600 Ohm

Noise (A-weighted): -121 dBu

Noise (A-weighted, Parallel Mix active): -104 dBu

Noise (A-weighted, Parallel Mix, Gain active): -102 dBu

Crosstalk (at 1 kHz at 0 dBu): -130 dB

Crosstalk (at 1 kHz at 0 dBu Parallel Mix active): -110 dB

Crosstalk (at 1 kHz at 0 dBu Parallel Mix, Gain active): -80 dB

THD & N (at +20dBu): › -112 dBu

Common-Mode-Rejection (at 0 dBu): -75 dB

Transmission Bandwidth: 10 Hz-200 kHz 10 Hz = -0,12 dB; 100 kHz = -0,3 dB; 200 kHz = -1,2 dB



Power Consumption:

0,17 Amp, 230V/50Hz, 30 Watt, 37,6 VA

0,34 Amp, 115V/60Hz, 30 Watt, 37,6 VA



Fuses:

230V/50Hz: 1 Amp

115V/60Hz: 2 Amp



Dimensions: Standard EIA 19 Inch Housing/2U: 482 x 88 x 300 mm / ca. 19" x 3,5" x 11,8" (front panel excl.)

Weight: 9kg/ 19,84 lb
