From Black Lion Audio
The B12A MKII 500 packs the same punch as its 1⁄2 rack cousin, but in the convenient and flexible 500 series format. The API®-style design features a delicious Cinemag input transformer, serves up huge portions of low-noise gain, and has the same classic American rock sound that the original API® 312A is known for! Get ready to fill your lunchbox®, ‘cause once you go Black Lion Audio, you never go back!
FEATURES
- 500 Series format (lunchbox® required)
-
Cinemag Input Transformer
-
Edcor Output Transformer
-
70dB Gain
-
Hi-Z Input (passive, unbalanced)
-
Phantom Power
-
18dB Pad
-
Phase Switch
Mic Section
- Max Microphone Input Level
- +1dBu
- Input Impedance
- 200Ω
- Pad
- 18dB
- Gain (no pad)
- +26dB to +70dB
- Equivalent Input Noise (noise floor)
- -120dBu
- THD+N (@ +4dBu output)
-
- .010% @ +22 dBu
- .010% @ +36 dBu
- .041% @ +56 dBu
- .122% @ +66 dBu
- Bandwidth (1kHz, 150Ω source, unweighted)
- 10Hz to 30kHz
D.I. Section
- Max D.I. Input Level
- +18dBu
- Input Impedance
- 1.1MΩ
- Pad
- none
- Gain
- +10dB to +53dB
- Equivalent Input Noise (noise floor)
- -94dB
- THD+N (@ +4dBu output)
- .009% @ +10 dBu
.115% @ +36 dBu
- Bandwidth (1kHz, 600Ω unbalanced source, unweighted)
- 10Hz to 30kHz
Output Section
- Max Output Level
- +28dBu
- Output Impedance
- 600Ω
Power Supply
+/- 15v (lunchbox® supply)
Product Dimensions
1.5” x 6.5” x 5.25”
Product Weight
.8 lbs
Shipping Dimensions
13” x 13” x 5”
Shipping Weight
3 lbs
