From BAE
- Made using Avedis® 1122 opamps
- Supplied with Jensen input and output transformers.
- Remote power supply with four-foot cable capable of four times the current needed by the preamps for optimum sound quality.
- Switches have gold contacts for long life.
- XLR connectors on the back for mic input and output and phone jack in front for direct input.
- High impedance direct input for guitar and synthesizer.
- Separate front panel switches for phantom power.
- Frequency Response
- 5Hz to 75kHz (-3dB)
- Mic Input Impedance
- ≈1400 ohms
- Line Input Impedance
- 10k ohms
- DI Input Impedance
- ≈250k ohms
- Output Impedance
- 75 ohms
- Common Mode Rejection Ratio
- 110dB min @ 60Hz
- Maximum Output Level
- +27.1 dBu @ 600Ω
- Power Requirements
- 115/230 VAC, 27W (Rackmount)
40mA per Rail (Module)
- Gain dB
- 10 to 66 dB
- Equivalent Input Noise
- 120 dBu; Unweighted 300kHz Bandwidth
- Weight (Module/Rackmount)
- 1 LBS / 0.45 KG (Module)
7 LBS / 3.18 KG (Single Rackmount)
8 LBS / 3.63 KG (Dual Rackmount)
Dimensions in Inches (Rackmount/Module)
19W x 1.75L x 9D (Rackmount)
1.5W x 5.5L x 6D (Module)
Free 3-Year Warranty
In addition to the standard included manufacturer warranty, virtually all new products carry our exclusive, industry-leading, absolutely free Sound Pure 3-Year Warranty, which includes parts and labor. It's our way of adding real value to the personal touch our small, dedicated team brings to every purchase.
Coverage exclusions live in Terms & Conditions, Section 27. Read the warranty →
