From TELEFUNKEN Elektroakustik
Blending an Austrian-inspired voicing similar to the legendary C12 with modern FET high performance, the phantom-powered TF11 exhibits a beautifully open and detailed frequency response with exceptionally fast transient response, high SPL handling, and low self-noise. The compact, cardioid only TF11 is versatile, portable, and dependable for all recording environments from home to studio to stage.
Circuit Design
The TF11 features a unique combination of circuit elements shared with other TELEFUNKEN Elektroakustik designs. The CK12-style edge terminated capsule is a single membrane version of the capsule featured in the TF51. The amplifier is a unique proprietary take on the classic FET microphone amplifier similar to the M60, coupled with a custom large format nickel-iron core transformer made in the UK by OEP/Carnhill. Premium through-hole components include UK-made polystyrene film capacitors, Nichicon Fine Gold electrolytic capacitors, and a high-performance, ultra-low-noise JFET amplifier.
Features
◆ Cardioid polar pattern
◆ Compact travel and budget friendly design
◆ Open and detailed tone with fast transient response
◆ Designed and assembled by hand in the USA
◆ High SPL handling, low noise phantom-powered FET amplifier
◆ CK12-style capsule and UK-made OEP/Carnhill transformer
- Type
- FET Condenser
- Polar Pattern
- Cardioid
- Frequency Range
- 20 Hz – 20 kHz, ±3 dB
- Power Source
- +48V Phantom Power
- Capsule
- TK51S - Edge Terminated Large Diaphragm, Single Membrane
- Tube
- n/a
- Transformer
- OEP/Carnhill T218
- Sensitivity
- 14 mV/Pa, ±1 dB
- THD at 1kHZ at 1Pa (Amplifier)
- < 0.01%
- Output Impedance
- 110 Ω
- Maximum SPL (for 1% THD)
- > 135 dB
- S/N Ratio
- 90 dBA
- Self Noise (Amplifier)
- 4 dBA
- Dimensions
- 175 mm L x 46 mm Dia
- Weight
- 545 g
- Included Accessories
- Shock Mount, Stand Mount, Mic Sleeve, Mic Case
