Sound Pure's Take
Condition: Used, Excellent
Size
- Height
- 5.4 inches (140 mm)
- Width
- 3.5 inches (90 mm)
- Depth
- 2.3 inches (60 mm)
Weight
- Weight
- 0.92 lb. (0.42 kg)
Construction
Two part dies cast metal
Rubberized base
Connections
Analog Inputs
- Connectors, balanced
- Mic.: XLR
- Mic Input Level @ 0 dBFS
- -42dBu to +1dBu
- EIN @ Max Mic Gain Rg = 150 Ohm
- -126 dBu
- Mic input SNR
- >104 dB
- Phantom Power
- 24V (always on)
- Guitar Input impedance
- 1 MOhm
- Guitar Input Level @ 0 dBFS
- -7 dBU to 17 dBu
- Guitar Input SNR
- >115dB
- Dynamic Range
- >104 dB, 20 Hz to 20 kHz
- Frequency Response
- +0/-0.3 dB, 20 Hz to 20 kHz
Analog Outputs
- Output Impedance, Bal./Unbal.
- 200/100 Ohm
- Output Full Scale
- +1 dBu
- Dynamic Range
- >104 dB, 20 Hz to 20 kHz
- Frequency Response
- +0/-0.3 dB, 20 Hz to 20 kHz
Control
USB for firmware and control
Mic Control using TC Helicon MP-75
Safety And Regulations
Power
- Power Supply (Supplied)
- 12V .4A
- Power Consumption
- 5.6W
Safety
EMC – Complies with EN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B
Safety – certified to IEC 65, EN 60065, UL6500 and CSA IEC 65, EN 60065, UL6500 and CSA
Environment
- Operating Temperature
- 32°F to 122°F (0°C to 50°C)
- Storage Temperature
- -22°F to 167°F (-30°C to 70°C)
- Humidity
- Max. 90 % non-condensing
Warranty
This item is sold without the Sound Pure 3-year warranty (used / B-stock / dealer-exempt). Coverage terms for items in this category live in Terms & Conditions, Section 27.
