Suhr ISO Line Out Box - Used From Suhr Pedals

Suhr's ISO Line Out box.

Buy Pre-owned from Sound Pure with Absolute Confidence

Sound Pure's dedication to pre-owned products is unprecedented in the industry. We are a small team of dedicated experts that buys, trades, and consigns. We are trusted by customers all over the world. Our curated collection, is thoroughly tested and inspected by some of the best in the business. Our inventory is constantly changing, ever-evolving, with some items sold before reaching the website. Looking for something specific? Have questions about this product's condition or history? Want more photos, or to simply chat with an expert who's had his hands on this actual piece? Contact us now.

Our Current Used/Vintage Collection »

Sound Pure's Consignment Program »

Luthier Certification for Used Instruments »

"Gone, Baby, Gone"

This one is sold. Don't miss the next one. Some things never even make it to the site so stay up to date on our used collection.

We get in many oddities, rare and vintage products, most of which go fast. If you're on the hunt for something specific, something unique, or something priced right, let us notify you on our used collection before the items even hit the site.

Want to know if one lands?

Notify Me

Want to discuss what's coming?

Call Us! Toll Free! 888-528-9703
Local / International (+1) 919-682-5552

Talk with a Specialist

About Manufacturer

In our continuing effort to provide the very best tools for the serious musicians, we turned our attention to other links in the electric guitar signal chain. Having covered guitars, pickups, amps, cabinets and accessories such as the MiniMix II and ISO Line Out box, it was natural for us to further strengthen the entire signal path by developing a new line of pedals that will work superbly with our gear or with other manufacturers' products. Nearly two years in development, a lot of thought and time went into these pedals that will not only improve the overall sound of your rig, but provide added functionality and robust build quality that will provide many years of rock-solid performance under the most demanding playing environments.

Specifications

The ISO Line Out box is NOT a load box. In other words, the amplifier must have a speaker, or suitable load, connected at all times. The ISO Line Out box is not a speaker cabinet emulator.

Operation:

Connect any available speaker output jack to one of the Speaker Thru jacks on the ISO Line Out box. If the amp has only one speaker output jack, connect this to one of the Speaker Thru jacks on the ISO Line Out box and plug the speaker into the other Speaker Thru jack. Connect the Line Out jack to a balanced or unbalanced jack of your mixer, effect or recording device. Set the appropriate level.

Line Out:

The Line Out jack is wired for balanced or unbalanced connections. The transformer is wired to the tip and ring connections of the jack. The cable shield is floated and can be referenced to the box ground ONLY when a balanced cable is used.

Phase Switch:

The phase switch is used to invert the phase of the signal. Set the switch in the up position to invert the phase, down for normal phase.

GND Ref Switch:

The ground reference switch can be used to reference the box ground to the Line Out cable ground. This should ONLY be used with the use of a balanced cable. For mono cables, leave this switch in the down position.
