Rupert Neve Designs 5059 Satellite  From Neve

Inspired by many of the topologies and custom transformers made famous with the 5088 mixer and Portico II Series, the 5059 is designed to deliver the best “out of the box” sonics and ergonomics in a 2U, rack-mount chassis.

Rupert Neve Designs

$3,749.00

Retail:  $3,995.00

"Experience the Difference"

Sound Pure's 3-Year Warranty

Close
Our Free 3-Year Warranty!
In addition to the standard included manufacturer warranty, virtually all new products carry our exclusive, industry-leading, absolutely free, Sound Pure 3-Year Warranty, which includes PARTS & LABOR. This high-value perk is our way of providing the ultimate in added value to enhance the unique personal touch our small, dedicated team contributes to each purchase.
Learn more »

Lifetime Support

Close
Free Lifetime Technical Support!
Our small team of dedicated experts is here to help the original purchaser for the lifetime of the product. Why? Because we care about building real relationships with our customers for life and stand behind every product we sell.

Free Shipping

Close
This Product Ships Free!
Products ship from our well-located, climate- and humidity-controlled warehouse absolutely free (inside the continental USA). Low-cost international shipping options exist for most products.
Contact us for details »

No Sales Tax Outside North Carolina

Ships Quick!
Usually ships 24 - 48 hours after order processed.
Payments as low as $85/mo.

Using the 5059 and Master Buss Processor to improve a mix

Austin based engineer Danny Reisch of Good Danny's studio shows how he uses the 5059 Satellite Summing Mixer and the MBP to enhance a mix, using Tacks, the Boy Disaster's song "Treasure Hunters".

  • Signal Chain
    • Rupert Neve Designs 5059 Satellite

Manufacturer's Description from Neve

The 5059 features 16 channels with individual level, pan, inserts, stereo-2 sends, and master texture controls, providing easy integration with outboard equipment, complete control for two separate stem mixes, and the ability to dial in analogue mojo in two modes. With the same sonic heritage as mixers used to create countless hit records, the 5059 Satellite Mixer imbues tracks with the legendary warmth and presence of a Rupert Neve design.

The Signature of Excellence

The most important element of the 5059 is its legendary sound. The keys to the sonic prowess of the 5059 are the custom transformers and true class-A topologies found within. The class-A topologies in the 5059 have been fine-tuned over a number of years to provide exceptional sonic performance and completely eliminate cross-over distortion. When combined with Mr. Rupert Neve’s transformer design and implementation, the 5059 achieves a remarkable purity, while also conveying the signature warmth and larger-than-life sound reminiscent of Rupert’s classic designs.

Making Connections

One drawback to mixing “in the box” is the inability to use high quality analogue outboard equipment. Channel inserts are provided in the 5059 to streamline interconnections with analogue outboard equipment and to allow for further expansions of the 5059’s capabilities. By connecting a second 5059 to the insert outputs of a 5059, the dual stereo outputs can be used as a way to add 4 auxes to each of the 16 channels.

From Clean to Colored and Everywhere in Between

Every mix demands its own treatment; continuously variable Texture controls with Silk and Silk+ modes allow the engineer to fine tune the harmonic ratio and tonality of each stereo send of the 5059, or leave each mix pristine. The Silk mode accentuates the transformer saturation in the high frequencies to add a “sparkle” to tracks. The Silk + mode accentuates the saturation of the low frequencies to add thickness and density to any source – especially useful for dry, somewhat anemic mixes. Unlike EQ, the texture control saturates the output transformers, and adds musical harmonics to the source material according to the amount of texture applied.

Stem It or Sum It

Aside from providing aux functionality with a second 5059 module, the dual stereo outputs of the 5059 are generally used for creating stem mixes. These stem mixes can be enhanced using the Silk / Texture controls on the 5059, then processed by buss compressors or other devices, and fed into inputs of another mixer or an ADC.

With 16 channels of Rupert Neve designed class-A magic and numerous tonal and routing options, the 5059 Satellite mixer will elevate your DAW-based studio’s sound and performance to new heights.

Texture

Continuously variable control for Silk and Silk+ modes allows the engineer to fine tune the harmonic ratio and tonality of both stereo outputs.

New Class-A Topologies

With zero crossover distortion and unmatched purity, the 5059 sets the standard for rack-mountable summing mixers

Custom Transformers

Beyond providing galvanic isolation, the custom transformers in the 5059 are a key ingredient to its larger than life sound.

Dual Stereo Outputs

Split the input channels into two stems for further processing and mixing.

Channel Level

Individual level controls are provided for each channel from -∞ to +10dB.

Channel Pan

Individual pan controls are provided on each channel of the 5059 with a 3dB pan law.

Master Output Level

Level controls are provided for each of the stereo outputs -∞ to 0dB.

Rupert Neve Designs

About Manufacturer

Rupert Neve Designs, Inc. is nestled in the picturesque Texas Hill Country. Our small team of dedicated engineers have designed a new range of Professional Audio Gear and systems based on both proven classic design concepts and modern innovations. This new range of gear is based on custom designed transformer and single sided amplification

Specifications

Frequency Response:

  • 100K Load,
  • +/- 0.1dB from 20Hz to 20kHz
  • -3dB @ 3.5Hz / 185kHz

Noise:

  • IEC-A-Weighted
  • Buss Outputs: -106dBV
  • Single Channel assigned @ -∞: -104dBV
  • Single Channel assigned @ Unity: 103dBV
  • Single Channel assigned @ +10dB -100dBV

Un-weighted, 22Hz – 22kHz

Buss Outputs:

  • Single Channel assigned @ -∞: -101dBV
  • Single Channel assigned @ Unity: -100dBV
  • Single Channel assigned @ +10dB -97dBV

Signal to Noise:

  • +20dBu output un-weighted, 22 – 22kHz: 116dB
  • +20dBu output, IEC A weighted: 119dB
  • +4dBu output unweighted, 22 – 22kHz: 100dB
  • +4dBu output, IEC A weighted: 103dB

Output Level:

  • Summing Busses to XLR outputs, Maximum Output Level, 20Hz to 40kHz: +26dBu
  • Single Channel to Buss, Maximum Output Level, 20Hz to 40kHz: +24.5dBu

Total Harmonic Distortion and Noise:

  • 1kHz @+20dBu output: better than 0.003%
  • 20Hz @+20dBu output: better than 0.005%

Total Harmonic Distortion, Silk Engaged:

  • Blue Silk – 100Hz @+20dBu output, texture control 12 o’clock: 0.2% typical
  • Blue Silk – 100Hz @+20dBu output, texture control fully CW: 0.65% typical
  • Red Silk – 100Hz @+20dBu output, texture control 12 o’clock: 0.1% typical
  • Red Silk – 100Hz @+20dBu output, texture control fully CW: 0.35% typical

Slew Rate:

4V/uS

Crosstalk:

Buss1 to Buss2

  • 1kHz: Better than -90dB
  • 10kHz: Better than -70dB

Power Consumption:

  • AC Mains, 100VAC to 240VAC, 50/60Hz: 45 Watts
  • Fuses – not user accessible, internal on power supplies

Size/Weight:

  • Size: 3.5”H (2U), 19”W, 8”D
  • Weigh: 23lbs
  • Shipping size: 22” x 17” x 8”
  • Shipping Weight: 25lbs
