From Neumann USA
The TLM 127 is a multi-pattern large diaphragm microphone ideal for all professional and semi-professional applications requiring the utmost in sound quality. By utilizing the tried and true tranformerless circuitry found in numerous Neumann microphones, the TLM 127 features low self noise and extremely high sound pressure level transmission. The dual diaphragm capsule, derived from that used in the TLM 103, is acoustically well balanced, and offers multiple polarity from the microphone, switchable pad (-14 dB) and a high pass-filter. Cardioid and omni switchable patterns currently available on microphone, with a full range of five patterns available via optional remote control and power supply using standard XLR cables. This remote will be availabe in 2004.
The TLM 127 is available in satin nickel or matte black. Delivery includes an EA 1 shock mount and a wooden jeweler's box.
Applications
Due to the multiple polarity, high sound pressure capabilities and extremely low self noise, the TLM 127 is destined for universally demanding applications from home recording to professional broadcasting and commercial recording studios.
- Acoustical operating principle
- Pressure gradient transducer
- Directional pattern
- Omnidirectional, cardioid, (wide angle cardioid, hypercardioid and figure-8 also available, via remote control)
- Frequency range
- 20 Hz...20 kHz
- Sensitivity at 1 kHz into 1 kohm
- 12 mV/Pa
- Rated impedance
- 50 ohms
- Rated load impedance
- 1000 ohms
- Equivalent SPL CCIR 468-3
- 20 dB
- Equivalent SPL DIN/IEC 651
- 8 dB-A
- S/N ratio CCIR 468-3
- 74 dB
- S/N ratio DIN/IEC 651
- 86 dB
- Maximum SPL for THD 0.5%
- 140 dB
- Maximum SPL for THD 0.5% with preattenuation
- 154 dB
- Maximum output voltage
- 10 dBu
- Dynamic range of the microphone amplifier DIN/IEC 651
- 132 dB
- Supply voltage
- 48 V
- Matching connectors
- XLR 3F
