Manley Massive Passive Stereo Tube EQ  From Manley

Manley’s tube stages handle huge HF boosts without sibilance and unbelievable fatness without mud. “It’s like a Pultec on steroids.”

Manley Laboratories Inc

$5,599.00

Retail:  $5,600.00

"Experience the Difference"

Sound Pure's 3-Year Warranty

Close
Our Free 3-Year Warranty!
In addition to the standard included manufacturer warranty, virtually all new products carry our exclusive, industry-leading, absolutely free, Sound Pure 3-Year Warranty, which includes PARTS & LABOR. This high-value perk is our way of providing the ultimate in added value to enhance the unique personal touch our small, dedicated team contributes to each purchase.
Learn more »

Lifetime Support

Close
Free Lifetime Technical Support!
Our small team of dedicated experts is here to help the original purchaser for the lifetime of the product. Why? Because we care about building real relationships with our customers for life and stand behind every product we sell.

Free Shipping

Close
This Product Ships Free!
Products ship from our well-located, climate- and humidity-controlled warehouse absolutely free (inside the continental USA). Low-cost international shipping options exist for most products.
Contact us for details »

No Sales Tax Outside North Carolina

Ships Quick!
Usually ships 3 - 5 business days after order processed.
Payments as low as $127/mo.

Want a lower price?
Call or email us!
888-528-9703
sales@soundpure.com

What We Think

You can find it in just about every mastering studio in the world, the Manley Massive Passive is an exemplary powerhouse of an equalizer. Simultaneously bold yet transparent, the subtle rounded tone of this pultec-style EQ has everything you could ever ask for if you're looking to achieve perfect tonal balance for your mixes.

On the outside, this machine is crafted with care and precision to achieve that classic studio feel while at the same time not looking out of place on the interior of a NASA spaceship.

These units are built like tanks and each one undergoes rigorous quality assurance before ever leaving the factory so you can rest assured knowing your product will be ready to use the minute you unbox it.

For engineers all over the world, the Massive Passive offers up the luxury of having a precise yet unobtrusive passive equalizer that will help form-fit your mixes into the sonic masterpiece they were intended to be. Out of all the players in the Pro Audio game right now, Manley has proven itself time and time again to be a name you can trust.

Manufacturer's Description from Manley

A PICTURE IS WORTH A THOUSAND WORDS...

Perhaps, but would photographs of our Variable Mu® Limiter Compressor or VOXBOX® have created their successes alone? You have to hear this gear. You have to use this gear. Put your hands on the knobs and crank 'em. Engineers who have already gotten hold of the MASSIVE PASSIVE have told us: "Why does it make everything sound so much better?", "It's organic and orgasmic.", "It's a f%#king powerhouse.", "It's unlike any other EQ.", "This is IT. The sound I've always dreamt of but couldn't ever get until now."

GOT THE PICTURE?

The MASSIVE PASSIVE is a two channel, four band equalizer, with additional high pass and low pass filters. "Passive" refers to the tone shaping part of this clever new EQ design not using any active circuitry. Only metal film resistors, film capacitors and hand-wound inductors sculpt the sound, kinda like a Pultec EQ on hyper-steroids. Super-beefy, hugely-high-headroom Manley all-tube make-up gain amplifiers deliver your tunes into the next realm. "Massive".... it's a fitting word for this beast. You'll need to experience this.

Creating natural, organic, acoustic tone can only be done with an equalizer that treats the signal with natural methods. The Massive Passive uses simple passive components and exploits their natural qualities rather than forcing a complex circuit to meet an arbitrary clinical or scientific goal. Manley knows that recording and mastering equalizers are used by artists for artistic goals and we balanced this design with a little more art than science. The Massive Passive is intended both for the most radical EQ sometimes needed for tracking as well as the most subtle shadings for vocals and mastering. It is designed to be a fundamentally different EQ but incorporates the best strengths of Pultecs, choice console EQs, parametrics and graphics. The difference is that the Massive allows twice as much EQ with half the coloration. It allows huge HF boosts without sibilance problems and unbelievable fatness without mud. This is unique. Being different also gives it some quirks and idiosyncrasies that will spark your creativity and sense of audio adventure. We could attempt to use dozens of superlatives to describe the sounds, but really, you have to experience it yourself. Words cannot do it justice. The astute reader will notice a lack of "buzz words" and that the Massive Passive is not built around gimmicks, plagiarisms, or conventional techniques. However, it is built to complement our Variable Mu® Limiter Compressor for instance.... This combo could just be the ultimate processing chain. It's already a Mastering fave. To this end we finally have a new dedicated Mastering Version Massive Passive Stereo EQ available too.

FEATURES:

  • All-Passive tone sculpting circuitry
  • Unique Shelf curves use the "bandwidth" control
  • Overlapping and Interleaved Frequency choices
  • Every band switchable to shelf or bell
  • Vacuum tube make-up gain and line drivers
  • Parallel symmetrical topology
  • Premium components throughout
  • Passive HP and LP Filters plus gain trims
  • Modular design that allows future upgrades and special functions. The Massive Passive is an "EQ platform" with room to grow.
  • Transformer balanced floating outputs for ease of installation and a touch of desirable flavor. These too were custom designed for the Massive Passive to accommodate the huge boosts possible.
  • Manley quality, Manley engineering, and the "Manley Sound".

The Filters

There are 5 High Pass Passive Filters and bypass, plus 5 Low Pass Passive Filters with bypass. We made them extra steep. Why? So you can remove the garbage and not mess up your music. The way these filters interface with the parametric EQ bands simply sound beautiful. The highest Low Pass filters get even steeper. Attack drums, guitar stacks, and other tough jobs. Make "telephone" voice sounds for special effects.

High Pass Filters = 22, 39, 68, 120, 220 Hz, OFF

Low Pass Filters = 6 kHz, 7K5, 9 kHz, 12 kHz, 18 kHz, OFF

Parametric Frequencies

LOW - 22, 33, 47, 68, 100, 150, 220, 330, 470, 680, 1K

LM - 82, 120, 180, 270, 390, 560, 820, 1K2, 1K8, 2K7, 3K9

HM - 220, 330, 470, 680, 1K, 1K5, 2K2, 3K3, 4K7, 6K8, 10K

HI - 560, 820, 1K2, 1K8, 2K7, 3K9, 5K6, 8K2, 12K, 16K, 27K

Each band can be bypassed or set to boost or cut. This provides twice the control resolution over conventional EQs. It also eliminates the problem of a center detent not guaranteeing flat response.

Each band is capable of 20 dB of boost or cut combined with amazing headroom and freedom from clipping.

Steep LP and HP filters for maximum effectiveness and achieved passively for minimal coloration. Low Pass Filters get progressively steeper as the frequency point rises. All of the High Pass Filters, and the Low Pass 6K, 7K5, and 9KHz Filter slopes are 18 dB/octave, the Low Pass 12kHz filter has a 24dB/octave slope and the 18kHz filter has a 60 dB per octave slope.



Manley Laboratories Inc

About Manufacturer

The MANLEY brand has been around since the late 1980's. Manley's first commercially available products were upper echelon high-fidelity vacuum tube amplifiers and preamplifiers constructed at the old Vacuum Tube Logic of America factory.

In this history lesson, we'd like to direct special focus on our people at Manley Labs. The people whose years of dedication, service, and expertise bring you people, our customers, these products. It's all about the people...

On January 30, 1989, a 20 year old EveAnna on sabbatical from her studies at Columbia University met the crew and was hired on to the production team. Baltazar Hernandez, already with two years experience, taught her how to solder in those first few days. It was in 1989 that the first Manley professional products were developed, starting with the original 1u Reference 60dB Microphone Preamplifier and soon followed by our Manley Enhanced Pultec and Mid Frequency Equalizers. Baltazar and EveAnna, busy building gear, were soon joined by Saulo and Ramiro. Just next door, Elias was employed by a printed circuit board maker later brought into the Manley Labs fold when in 1993, Manley Laboratories, Inc. became a separate entity apart from VTL. The new Manley Labs factory at 13880 Magnolia Ave. in beautiful and bovine Chino, California was outfitted to house the Manley HiFi and Pro Studio manufacturing as well as the Langevin production lines, our newly acquired machine shop, and printed circuit board facilities.

Specifications

  • Ins & Outs Balanced XLR & 1/4" (accepts unbalanced)
  • Level +4 dBu nominal, internal switches for -10 operation
  • Bypass Switch bypasses EQ & tube circuits (not hardwire)
  • 44 Frequencies (roughly 1/4 octave spacing)
  • Frequency Range: 22 Hz to 27 kHz
  • EQ Boost/Cut Range : 20 dB boost, 20 dB cut
  • Nominal Q range: 1.5 to 3 (uniquely active in shelf modes)
  • Frequency Response: ±2 dB: 8 Hz to 60 KHz
  • Maximum Output @ 1.5% THD +37 dBv; +26dBv @ 20 Hz
  • THD & Noise (1KHz @ +4 dBu): 0.06%
  • Noise Floor (referred to +4dBu): -85 dB (A Weight)
  • Dynamic Range: 120 dB
  • Tube Complement: 2 x 12AX7 EH, 4 x 6414 for serial MSMPX### after 2/2004
  • Tube Complement: 2 x 5751, 4 x 6414 for serial MSMP### until 2/2004
  • Power Consumption (120/240VAC): 72 watts
  • Unit is factory set for 100V, 120V or 220-240VAC operation for original destination country's mains voltage.
  • Operating Mains Voltage changeable with power transformer changeover switch and fuse value change.
  • Mains Voltage Frequency: 50~ 60Hz
  • Size (3U): 19" x 5.25" x 10"
  • Weight: Unit 21 lbs.
  • Shipping Weight: 27 lbs.
