From Eventide
SPECS
Analog InputMAX Input Levels, Input Impedance
- INST IN
- +10dBu, 500kΩ
- 1/4" Line IN
- +24dBu, 22kΩ
- XLR Mic IN
- +4dBu, 2kΩ
- FROM FX
- +10dB, 200kΩ
- AUX IN
- +4dBu, 5.0kΩ
Analog OutputMAX Output Levels, Output Impedance
- TO FX
- +10dBu, 400Ω
- TO AMP
- +10dBu, 250Ω
- PHONES
- 150mW per channel, min Load = 8 Ohms
- DI/LINE OUT
- (DI) -10dBu, (LINE) +18dBu, 200Ω
- AUX OUT
- 18mV, 200Ω (mobile mic level)
- Power Supply
- 9 VDC, 500 ma, center pin (-)
Min. required current at 9VDC = 200mA
- Dimensions
- English: 3.6” (H) x 2.65” (W) x 1.5” (D)
- Metric
- 91(H) x 67(W) x 38(D) mm
- Weight
- .96 lb / .43 kg
