SYSTEM PERFORMANCE

Bandwidth: 20Hz to 20kHz, +0/-0.5dB

Frequency Response: < 3 Hz to > 90 kHz, +0/-3 dB

Dynamic Range: > 106 dB, unweighted, any output

Signal-to-Noise: Ref: +4 dBu, 22 kHz measurement bandwidth

THD + Noise: < 0.004% at +4 dBu, 1 kHz
< 0.04% at +20 dBu, 1 kHz

Interchannel Crosstalk: < -80 dB, 20Hz to 20 kHz

Common Mode Rejection: Ref: +4dBu, 22kHz measurement bandwidth

Stereo Mode >94dB (Low Output)
>93dB (Mid Output)
>90dB (High Output)

Mono Mode: >94dB (Low Output)
>94dB (Low/Mid Output)
>92dB (High/Mid Output)
>88db (High Output)

POWER SUPPLY

Operating Voltage:100-120 VAC 50/60Hz; 120 VAC 60Hz 230 VAC 50/60Hz

Power requirements: 15W

Operating Temperature: 32°F to 113°F (0°C to 45°C)

PHYSICAL

Dimensions: 1.75" H X 6.9" D X 19" W (4.5cm x 17.5cm x 48.26cm)

Weight:4.0 lbs. (1.8 kg)

Shipping Weight:5.8 lbs. (2.6 kg)

• TRS differentially balanced ins and outs
• Mode switches for mono 4-way or stereo 2-way/3-way operation
• Low frequency summed (subwoofer) output
• x10 range switch on both channels
• 40Hz high pass (low cut) filter both channels
• Phase reverse switch on all outputs
• Individual level controls on all outputs
• 24dB per octave Linkwitz-Riley filters (the professional standard)
• Stereo/Mono status LEDs indicate the selected mode
• dbx® 2-year parts and labor as standard
• CSA NRTL/C approved
• CE compliant
