Power Rating: 60 watts

Frequency response: 60Hz-18kHz

Speaker: 8" [200mm] twin-cone system

Two channels

Phantom power: 24v [channel 2]

Dimensions:

Height: 10.24"

Width: 13.00"

Depth: 9.06"

Weight: 18 lbs

    Input for a 1/4" jack plug

    High/Low switch to adjust input sensitivity High impedance  instruments with a piezoelectric pick-up, Low for instruments with active pre-amplifiers and magnetic sound pick-ups

    Clipping indicator

    Gain input level control

    Color mid-range contour filter

    Bass tone control for low frequencies

    Middle tone control for mid-range frequencies

    Treble tone control for high frequencies

    Input XLR combination with an input for a 1/4" jack plug and XLR male socket

    Line/Mic switch adjusts input sensitivity

    Line sources with line level, instruments with active preamplifiers and magnetic

    sound pick-ups, Mic: symmetrical microphone input with 30V phantom source

    Clipping indicator

    Gain input level control

    Bass tone control for low frequencies

    Treble tone control for high frequencies

    Eff. Pan panorama control is for distributing the effects between the channels

    Select push button to choose between four effects, indicated by the LEDs between return and master (pos.1 warm hall, pos. 2 bright hall reverb, pos. 3 chorus with reverb, pos. 4 flanger)

    Return level control for internal effects

    Power indicator light

    Master level control

    Headphone output

    Tuner output

    Line out

    DI-out XLR output

    Send output for an external device

    Return input for effects or CD player

    F/S connection for a double foot switch

    Power combined mains switch
