Sound Pure's Take
It’s not near as common to see a ribbon microphone on vocals than a condenser microphone, but when the vibe of the song calls for an impeccably rich, impressively smooth, and vintage-leaning vocal timbre, the AEA R44CX delivers in an incredibly powerful way. As an accurate replica of one of the most classic microphones ever made (RCA 44), the R44CX boasts a velvety smoothness and unique tone that’s near identical to its origination. The CX model adds additional flexibility with a hotter output, which allows the microphone to be used with such a wide variety of preamps (not just those specifically designed to work optimally with ribbon microphones). This in turn provides the engineer with limitless creative freedom regarding preamp choice and also causes it to perform more consistently on dynamic vocalists by picking up more of the quieter sections.
From AEA
- An accurate reproduction of the original RCA Ribbon Mic
- Uses the same ribbon material as the original
- Built to the highest studio standards possible
- A single diaphragm Figure 8 ribbon microphone
- 90dB down broadband at 90 degrees
- Custom AEA Transformer
- High SPL capability, max level is 140dB plus above 200Hz
- Low Self Noise
- Consistent polar response
- Operable in high humidity environments
- Sounds equal to or better than the original RCA 44
- ‘X’ motor option delivers 6 dB more dynamic range
RCA 44 ribbon microphones have remained an essential part of studiolife well after RCA stopped manufacturing them in 1955. The sound and response of the 44 B/BX were unlike anything else available, and was cherished for its smoothness, forgiving nature and unique tonal balance. As collectors began to buy up the supply of RCA 44's through the 90's, the availability of this wonderful ribbon mic to the studio was greatly endangered. Wes Dooley, a specialist in ribbon mics of all kinds, recently began a project to restore availability of the RCA 44 to its rightful position in the studio. After tracking down the folks who built and designed the original RCA 44, Wes company, Audio Engineering Associates, acquired the ribbon material, made the tooling and custom machined the parts necessary to build the original. RCA 44 B/BX design as it was in the 1930s. After years of painstaking work, AEA has again begun production of the most important ribbon mic of all time: the AEA R44C and R44CE.
Whether it be the smooth brass section of a Hollywood soundtrack, the velvety lushness of a jazz vocal, or the larger-than-life drum sound of a classic rock record - chances are that you will find a 44 ribbon mic used on most of your favorite albums. In studio use for more than 80 years, the 44 ribbon design by RCA is as rich in history as it is in sound and character. When the company’s microphone division was closed down in 1976, we at AEA began servicing ribbon microphones, and by 1998 we were manufacturing 100% of the parts for the 44, resulting in the release of our very own version of this classic mic. Its recognizable sound produces thunderous lows due to the strong proximity effect, full and rich mids, and a unique top end to take the edge off of harsh instruments. This beautiful, natural-sounding microphone provides an unmatched authenticity of sonic reproduction, particularly when placed at a distance in a well-tuned room. The CE (cost effective) version delivers exactly the same sound as the R44C with absolutely no exceptions. By simplifying the exterior trim of the microphone and reducing manual labor for assembly, we are able to offer a more affordable 44 model for those of us who don’t require the polish and museum-grade finish of the 44C version.
*Operating Principle: Velocity microphone
*Frequency Response: Below 30 Hz to above 20 kHz
*Maximum SPL: 140 + dB SPL above 200Hz for 1% third harmonic
*Output Sensitivity: 2.25 mV / Pa into unloaded circuit
* Output Impedance: 270 ohms broadband
*Recommended Load: 1.2 K ohm or greater
*Powering: Not required or recommended
*Polarity: Pin 2 high for positive pressure on the front of the microphone
*Connector: XLR-3M wired to a 2 meter captive cable
*Polar Pattern: Native bi-directional pattern
*Horizontal: Level changes with angle, frequency response is consistent, -90 dB null at 90 / 270 degrees
*Vertical: Level changes with angle, reduced HF response above and below 0 / 180 degree axis, null at 90 / 270 degrees
*Transducer element: *Ribbon Thickness: 1.8 microns ( .0000018 meter ) of pure aluminum
* Ribbon Width: 4.7 mm
* Ribbon Length: 59.7 mm
*Accessories: *Included: Custom storage / shipping case, stand adapter, manual and attached two-meter microphone cable
*Limited Warranty: Three years parts and labor, shipping not included
