If you are looking for a lightweight and portable guitar head, look no further. The Clarus 2R works great for bass, electric guitar, archtops, acoustic guitar, and even vocals. Combo jacks allow you to plug a mic in, even a condenser that needs phantom power! On board effects, EQ and notch filter really allow you to shape your tone. Combine it with your favorite speaker cab and you are ready to go.
The Clarus amps were designed to accurately reproduce the sound of all acoustic and electric instruments without compromise or the size and weight that has traditionally be associated with high quality amplification.
Unlike other solid state amps, the Clarus has a distinct, warm sound, more like a tube amp. In addition, the Clarus is not "voiced" like many electronic instrument amps. So its frequency response is flat. This means that, with a high quality speaker system (like the Contra EX), what you hear is your sound of your instrument. The tonal shaping characteristics of the three-band EQ are sufficient to overcome room acoustics or to shape your sound without adding noise to the signal.
At the heart of the Clarus is a powerful Class D switch mode amplifier that runs cool yet delivers up to 500 Watts of clean, full spectrum power into speaker loads as low as 2 ohms. Other features include a parallel effects loop with a return level control, a selectable notch or low cut filter for feedback or "boominess" elimination and a balanced direct out with ground lift and pre/post EQ selection to allow connection to a mixing board for PA augmentation or recording. A switch for dual voltage operation (115/230V, 50/60 Hz), a detachable power cord and a padded gig bag with shoulder strap make the unit convenient for the travelling musician.
Clarus amps are for the working player looking for exceptionally clean, natural sound, with wide frequency response and low noise. Carried in one hand, or in the supplied gig bag, they provide an exceptional combination of pure sound reproduction and portability.
Clarus: 400W, with one channel or two...plus effects.
-Extended frequency range, high fidelity sound
-Light weight (5 lbs.), small size (10.2 x 8.2 x 3.5)
-Unique, slanted front chassis with built-in handles on side rails
-Combo jack input (either 1/4" or XLR)
-Phantom power on XLR input
-Three-band EQ preamp section per channel
-Input and master level controls
-Effects loop with return level control per channel
-Switchable notch/low cut filter per channel
-Balanced direct out with ground lift
-Digital effects with 6 presets and level control (C2R)
-Mute switch and pre/post EQ for direct out
-Stereo capable with external power amp (C2R)
-400 W switch mode power amplifier
-Switchable dual voltage operation (115/230V)
-Dual speaker outputs via Speakon connectors
-Comes with padded case, 6 foot speaker cable
Although Acoustic Image is a relatively young company, it is owned and operated by people with decades of experience in the professional music and sound industry. They're engineers (and, like their customers they're also musicians) who insist upon superior sound quality and reliable performance from our audio equipment. Acoustic Image was founded because they were never satisfied with the products available for the working musician. If you play guitar or bass, violin, keyboard, a woodwind or even a brass instrument, or you are a vocalist, they've got a sound reinforcement product designed with you in mind. Great product designs go far beyond having the right knobs in the right places. Acoustic Image’s company charter is to design and build unique, innovative, and functional audio products... there is nothing "me too" about what they do. In essence, they have merged advanced acoustic design and switching amplifier technology to create incredibly compact, ultra-lightweight products offering highly accurate sound for serious musicians. Ultimately, their pledge to you is for quality... to build a well-constructed reliable audio product that serves you well night after night, year after year. And, quite frankly, they believe the best way to do that is to design and manufacture each and every Acoustic Image product in the U.S.A. Their Technology Applying "musical thinking outside the box", they have taken a different approach to the technology of musical instrument amplification in order to improve the performance and portability of combo amps for the working musician. So, what's so unique about their products? There are three key differences: 1) The use of downfiring low frequency drivers 2) The use of switching power amplifiers and switching power supplies instead of the traditional linear designs 3) The use of unique enclosure shapes to improve portability and sonic performance Each of these differences provides an improvement in the performance of their products. Here's how: The downfiring woofer makes a small driver sound bigger and allows a smaller enclosure for a given driver size. Omnidirectional output produces a more natural and more transparent sound, and means you are more easily heard on the bandstand. The switching (Class D) amplifier design is smaller and more efficient than traditional linear amps. It has less weight because there are no heatsinks or cooling fans and it has a unique "warm" sound (unlike traditional solid state amps) because its output stage is radically different from traditional amps. The switching power supply eliminates large bulky power transformers with a resulting dramatic decrease in weight. With their unique enclosure shapes, form follows function. A cylinder is an inherently stiffer enclosure. And no resonances in the enclosure walls means less coloration in the sound. Also, the stiffer enclosure allows the walls to be thinner and lighter in weight. Add to that the use of acoustically inert polymer materials and the cabinet becomes ultra light. We don't use these new technologies to “be different.” They use them because they make their products better. It all adds up to a more portable, better sounding products. Because of their small size and high sound quality, they virtually disappear on stage, leaving the sound of the instrument being amplified, only louder.
|
System |
Clarus 1 |
Clarus 2R |
|
Frequency Response |
20 Hz - 20 kHz, ± 0.5 dB |
|
|
Distortion |
<0.5% full output, <0.1% typical |
|
|
Hum and Noise |
-85 dB or better |
|
|
AC Power |
115V/60Hz, 230/50Hz, switchable |
|
|
Size |
10.2 x 8.2 x 3.5 inches |
|
|
Weight |
less than 5 pounds |
|
|
Preamp (mic and instrument inputs through combo jack) |
||
|
Mic Input |
600 ohm balanced, XLR connector |
|
|
Phantom Power |
38 volts, on/off switch w/LED indicator |
|
|
Instrument Input |
1 Mohm impedance, 1/4" jack |
|
|
Direct Out |
+4 dB, balanced, XLR connector, ground lift, pre/post EQ selector |
|
|
Effects Loop |
Parallel type with return level control |
|
|
Bass Control |
Shelving type, ±15 dB @ 60 Hz |
|
|
Mid Control |
±15 dB @ 650 Hz |
|
|
Treble Control |
Shelving type, ±25 dB @ 10 kHz |
|
|
Notch Filter |
>-18 dB sweepable from 30 to 800 Hz |
|
|
Low Cut Filter |
-12 dB/octave sweepable from 30 to 800 Hz |
|
|
Effects |
||
|
Type |
Digital with 6 presets and level control |
|
|
Program presets |
3 reverb (hall, room, plate), delay, ambient chorus, flange |
|
|
Power Amp |
||
|
Topology |
Class D (PWM) |
|
|
Switching Frequency |
200 kHz |
|
|
Output Power |
>250 Watts (8ohm) |
|
|
Minimum Load |
2 ohms |
|
|
Output Connectors |
Neutrik Speakon type (pole 1) |
|
|
Included Accessories |
||
Special guests John Buscarino and Craig Wagner demonstrate the new Chameleon Speaker at Sound Pure Studios. Guitar played is a beautiful Buscarino Virtuoso Archtop, sent through an Acoustic Image Clarus 2R into the Chameleon Speaker.
Benedetto Bambino Deluxe electric guitar(neck pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge Stealth 10ER cabinet mic'd with Peluso 22 251(i foot off) into A Designs Pacifica preamp feeding Lynx Aurora A/D converters.
Benedetto Bambino Deluxe electric guitar(neck pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge Stealth 10ER cabinet mic'd with Peluso 22 251(i foot off) into A Designs Pacifica preamp feeding Lynx Aurora A/D converters. (view less)
Benedetto Bambino Deluxe electric guitar(coil tap, bridge pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters.
Benedetto Bambino Deluxe electric guitar(coil tap, bridge pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters. (view less)
Benedetto Bambino Deluxe electric guitar(bridge pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters.
Benedetto Bambino Deluxe electric guitar(bridge pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters. (view less)
Benedetto Bambino Deluxe electric guitar(coil tap, neck pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters.
Benedetto Bambino Deluxe electric guitar(coil tap, neck pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters. (view less)
Benedetto Bambino Deluxe electric guitar(middle pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters.
Benedetto Bambino Deluxe electric guitar(middle pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters. (view less)
Benedetto Bambino Deluxe electric guitar(neck pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters.
Benedetto Bambino Deluxe electric guitar(neck pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters. (view less)
Benedetto Bambino Deluxe electric guitar(coil tap, neck pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters.
Benedetto Bambino Deluxe electric guitar(coil tap, neck pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters. (view less)
Benedetto Bambino Deluxe electric guitar(neck pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters.
Benedetto Bambino Deluxe electric guitar(neck pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters. (view less)
Benedetto Bambino Deluxe electric guitar(coil tap, middle pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters.
Benedetto Bambino Deluxe electric guitar(coil tap, middle pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters. (view less)
Benedetto Bambino Deluxe electric guitar(neck pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters.
Benedetto Bambino Deluxe electric guitar(neck pickup) played into Acoustic Image Clarus 2R Head into Raezer's Edge NY 8ER cabinet mic'd with Peluso VTB into Avalon AD-2022 preamp feeding Lynx Aurora A/D converters. (view less)
