Sound Pure's Take
Condition: Used, Excellent
From Other (Miscellanous Used/Vintage/Consign)
The TS1 “Tone Secret” amp was originally released in 2010 and it has been one of the most iconic amplifiers we have had the pleasure to build.
The TS1 is a nod to the classic overdrive, cascading gain stage amplifier and we wanted to put our take on this design. Featuring a full tube buffered effects loop and an overdrive channel that is incredibly touch-sensitive with a rich sustain that will inspire you to express yourself in new and creative ways.
In 2020, we changed the layout from previous incarnations of this amplifier to give you more tonal shaping options and performance.
- AMP CONFIGURATION
- 2 Channel Cascading Gain Platform
100w/50w (4)6L6 (half power scaling)
50w (2)6L6
40w/20w (4)6V6 (half power scaling)
- CHANNELS
- Foot switchable FET, lead, and tone stack bypass
- EFFECTS LOOP
- Tube buffered with individual level controls, bright switches, and on/off switches for both the send and return. This allows the player to configure the loop in multiple ways: fully buffered active loop, half buffered active loop, or passive loop.
- SPEAKER OUTPUTS
- 4ohm, 8ohm, 16ohm
- HEAD DIMENSIONS
- 20 5/8"W x 12"H x 10 5/8"D (43 LBS)
SPEAKER SPECS
- Watts
- 100
- Resonant Frequency (Fs)
- 100.14 Hz
- DC Resistance (Re)
- 8.04 Ohm
- Coil Inductance (Le)
- 0.33 mH
- Mechanical Q (Qms)
- 6.08
- Electromagnetic Q (Qes)
- 0.78
- Total Q (Qts)
- 0.69
- Compliance Equiv. Vol. (Vas)
- 16.03 cu ft
- Mech. Compliance of Susp. (Cms)
- 0.08 mm/N
- BL Product (BL)
- 13.95 T-M
- Diaphragm Mass Inc. Airload (Mms)
- 29.95 grams
- Surface Area of Cone (Sd)
- 366.10 cm squared
- Sound Pressure Level (spl)
- 99.94 db
CABINET SPECS
Our open back 112 is a portable and light weight cabinet. These cabs feature void-free multi-ply birch construction, special bracing, tuned back, sides, and baffle, as well as a tuned rear port. The result is a stunningly lively cabinet with a huge sound-stage and even bass dispersion.
- IMPEDANCE
- 8 Ω
- POWER HANDLING
- 100 WATTS
- DIMENSIONS
- 24.25″ WIDE, 18″ TALL, 12″ DEEP
- WEIGHT
- 36 LBS
