All-tube dual-channel preamp module packing both iconic Friedman BE and HBE high-gain tones.
$399.99
Custom-designed by Dave Friedman himself, the all-tube Synergy BE-DLX Preamp Module combines the iconic voicings of both the BE (Brown Eye) and HBE (Hairy Brown Eye) circuits into a single, highly flexible unit. Powered by two 12AX7 tubes, it features two identical channels equipped with independent Gain, Volume, 3-band EQ, a SAT (saturation) switch, and a BE/HBE toggle to smoothly shift between classic, responsive British crunch and high-gain drive. Deep tone shaping is available directly on the PCB, including a FAT switch for boosted low-end response, a Gain Structure switch to roll back gain for vintage textures, and a 3-position Cathode Select switch (preset to British voicing) to tailor input tube bass feel.
The Synergy Friedman BE, and HBE all-tube preamp modules were among Synergy’s most popular designs and for a good reason. They perfectly reproduce the tone and feel of Friedman’s legendary BE tube amplifiers, the standard by which all other modern, British-voiced amp heads are today judged.
Friedman is one of the most respected brands in tube amplifiers and thanks to Dave Friedman’s famed BE/HBE circuits, they’re as sought-after for their modern high-gain tones as they are for their classic roar.
Now, for the first time, with the BE-DLX you can get both the BE and HBE sounds from a single Synergy preamp module with more control than ever before.
DUAL CHANNEL ALL-TUBE
Like all Synergy Friedman modules, the BE-DLX was designed by Dave Friedman himself. Both all-tube channels are identical recreations of the BE tube preamp but feature a full, independent suite of controls, including volume, gain, and a 3-band EQ per channel for added flexibility. Their BE/HBE mini toggles takes you from responsive, bluesy crunch to the high gain used by today’s most respected rock and metal guitarists. Set one channel to a vintage rock crunch and the other to an HBE-powered modern metal tone. Or switch between a rhythm and boosted lead sound.
The BE-DLX module features two circuit board mounted switches. A two position FAT switch lets you add overall low-end response. The Gain Structure switch lets you reduce the gain of the module for a classic vintage tone.
The Synergy BE DLX module is like having two legendary Friedman amplifiers in one compact, all-tube, and incredibly convenient package.
CATHODE SELECT FUNCTION:
The Friedman BE-DLX module features a patented three-position switch on the PCB, which allows you to configure the input tube bass response to match the original circuit of the selected module. This will affect the feel and tightness. Each amp designer has a specific combination of components that make up their input tube circuit. Synergy has selected the three most popular combinations which you can access with this switch. The USA voiced modules typically use setting 1 (1.5K resistor and 22uf capacitor). British-style modules use position 2 (2.7K resistor and .68uf capacitor). The SOLDANO / VAI module use position 3 (1.8K resistor and 1uf capacitor). Of course, you can experiment and try any of the positions to see what you prefer. The BE-DLX is present to the center position 2 (2.7K resistor and .68uf capacitor).
Synergy hardware and interchangeable preamps are protected under US patent.
Amplifiers are basically a planned amalgamation of transformers, transistors, capacitors and tubes that can increase the power of a given input signal. However, the care, thought and expertise put into the choosing of the actual components, and how they are assembled affects the final tone in very unique ways.
When a reasonable amount of care is taken, combined with a mass market sensibility for components, you wind up with a decent sounding amp ready for mass production.
However, when painstaking attention is given to every aspect of every frequency an amp can produce, with a specific tonal ‘goal’ in mind, and only the finest components, masterfully assembled will achieve this goal, you’ve moved into the area of ‘boutique’ amplification. This method of creating amplified sound usually costs considerably more than mass produced amps, making them sometimes out of reach for the average player.
Typically, when a guitar player makes the leap to a boutique amp, they are so blown away by the difference in tone they now command, that they never want to play through anything else… until they play through another brand of boutique amp… now they want that one too! But, in order to afford it, most jump ship and sell the one they had to acquire the new one.
Enter Synergy Amps. After many years of contemplating that very phenomenon, and having a ‘no compromise’ attitude about tone, a unique concept was born.
Synergy module
What if we were able to get both boutique amp builders and popular mass amp builders alike to design their pre amp sections (which is responsible for the majority of the actual tone of their respective amplifiers) into a compact module, that would slide easily into a compact pre amp housing that we build, AND make it easily swappable with other modules? Also, make it so each module is 2 channels, easily hooks up to an existing amps effects loop, giving that amp 2 extra tube channels, and has a silent line out with cab sim for recording studios or to go straight into the mixing board at a show, eliminating the need for a bulky amp altogether…? Finally, make the price point so that anyone could afford it!
Well, that’s exactly what we did. And the idea is taking the industry by storm! Imagine the possibilities!
The player who though they just couldn’t afford a boutique amp now can!
The traveling musician that constantly worries about the quality of the backline amp he’ll have to use…problem solved!
The recording studio that would love to have all the best amps available to them. Or the home studio, that wants the same, but needs to keep the process ‘silent’.
We’ve taken every possible challenge scenario a guitar player might face, and built the solutions into the Synergy line. We invite you to plug in and be amazed like the rest of us!
All-tube preamp module custom designed by Dave Friedman
Two identical channels with Gain, Volume and 3-Band EQ
BE/HBE Switch per channel
SAT (Saturation Switch) per channel
PCB Mounted FAT switch (lets you add overall low-end response)
PCB Mounted Gain Structure switch (lets you reduce the overall gain)
2 x 12AX7 preamp tubes ensure rich harmonic performance
Easy to install and remove from Synergy preamp docks
