The JDI Stereo is a high performance 2-channel passive direct box for live concert touring and professional recording applications, featuring premium Jensen transformers for exceptional audio performance.
$379.99
Retail: $456.00
The Radial JDI Stereo is a passive two-channel direct box designed to handle extreme signal levels without distortion of any kind. It employs two world-class Jensen JT-DB-EPC audio transformers to deliver a smooth, warm sounding Bessel curve, reminiscent of the finest vintage gear. Ruler flat from 10Hz to 40kHz and with virtually zero phase deviation, the JDI Stereo delivers the natural, pure sound of the instrument without artifact. By its no-power passive design, the JDI Stereo performs both high-to-low impedance conversion and signal balancing over a magnetic bridge that passes signal while rejecting stray DC voltage. This makes it particularly adept at eliminating hum and buzz caused by ground loops.
Radial Engineering is a manufacturer and distributor of professional audio equipment, building tools for the working audio and audio-video professional. Radial is located on the Fraser River, just outside Vancouver, British Columbia in the municipality of Port Coquitlam. The company began operations in the fall of 1991 as the Canadian distributor of Mogami cable and Jensen Audio Transformers. In 1992, it became a limited corporation under the JP Cabletek Electronics Ltd. banner. The Radial name was first used on house branded cables and snake systems. The Radial name and logo represents a cross section of quad cable; Radial being round. In 1996 the Radial JDI direct box was launched. This led the way to the Radial JDV and today, over 50 electronic products are now being produced under the Radial, Tonebone and Forest Audio brands. In 2001, the Primacoustic brand was launched to address the growing demand for acoustic products for the burgeoning home recording market and in 2006, the company officially changed its name to Radial Engineering Ltd.
Audio circuit type: | Passive, transformer based | |
Transformer: | Jensen JT-DBE | |
Number of channels: | Two channels (dual mono) | |
Frequency response: | 20Hz ~ 20KHz (± 0.2dB) | |
Dynamic range: | 135dB | |
Total harmonic distortion: | 0.05% from 20Hz ~ 20kHz @-10dB | |
Phase Deviation: | 0.3° @ 100Hz; 3° @ 20Hz | |
Input Impedance: | 140k Ohms, unbalanced | |
Output Impedance: | 150 Ohms, balanced | |
Maximum Input: | +21dB @ 20Hz ~ 20kHz | |
Features | ||
Input pad, Ground lift | ||
Input Connectors: | Unbalanced 1/4" | |
Output Connectors: | XLR out, 1/4" thru | |
General | ||
Construction: | 14 gauge steel chassis & outer shell | |
Size (L x W x D): | 5" x 3.3" x 1.8" (127mm x 84.1mm x 45.5mm) | |
Weight: | 1.55 lbs (703 grams) | |
Shipping size (L x W x D): | 6.5" x 4" x 3" (165mm x 102mm x 76mm) | |
Shipping weight: | 1.92 lbs (870.9 grams) | |
Power: | Passive, no power required | |
Conditions: | For use in dry locations only between 5°C and 40°C | |
Warranty: | Radial 3-year, transferable |
