From Millennia Media
|
Authentic Transparency for Unrestricted Creativity |
|||||
|
|
Minimum Gain |
8.5 dB |
|
Maximum Gain |
|
|
(continuously variable) |
60 dB (70 dB in Ribbon Mode) |
|
Frequency Response |
|
|
+0 / -3 dB |
sub 3 Hz to beyond 300 kHz |
|
Noise |
|
|
60 dB Gain, 10 Hz - 30 kHz, Inputs common |
-133 dB EIN |
|
Total Harmonic Distortion + Noise |
|
|
35 dB Gain, 10 Hz - 20 kHz bandwidth, +27 dBu Out |
< .001%, Typ. < .0005% (< 5 ppm) |
|
Intermodulation Distortion |
|
|
(50 Hz & 7 kHz) 35 dB Gain, +27 dBu Out |
< .0009% |
|
Phase Response |
|
|
35 dB Gain, 50 Hz - 20 kHz bandwidth, +27 dBu Out |
< 2 degrees deviation |
|
Common Mode Rejection Ratio |
|
|
35 dB Gain, 10 Hz - 20 kHz bandwidth, 100 mV C.M. |
> 65 dB, Typ > 85 dB |
|
Slew Rate |
|
|
35 dB Gain, +27 dBu Out |
> 25 Volts per microsecond |
|
Maximum Input Level |
|
|
20 Hz - 40 kHz |
+20 dBu (no attenuator pads required) |
|
Maximum Output Level |
|
|
20 Hz - 40 kHz |
+28 dBu |
|
Phantom Input Impedance |
|
|
1 kHz |
6,750 ohms |
|
Output Impedance
|
24.3 Ohms (x2) |
|
Phantom Powering
|
+48 V dc, +/- 2 V dc |
|
Dimensions/Shipping Weight |
1.5” W x 5.25” H x 6” D, 3 lbs.. |
