From Mesa Boogie
The TONE-BURST™ Boost/Overdrive offers a virtually transparent gain range usually associated with “clean” boost pedals. However, the TONE-BURST has enough gain to boost your guitar to the threshold of clip and slightly beyond, making it far more useful for a variety of applications. It’s incredibly powerful for adding boost, drive and/or EQ to any guitar and amp combination. Whether using it as a utility to boost the output of single coils to match a humbucker or as a subtle overdrive when a standard overdrive may be too much, the TONE-BURST is an incredibly useful and expressive pedal that makes the best things sound even better!
PRODUCT FEATURES
Designed and Hand-Built in Petaluma, California, USA
True Bypass On/Off Switching - Bypasses all circuitry when off to ensure no tonal loss
Gain Control allows you to dial in the perfect amount of boost or mild overdrive
Master Level Control provides a variable range of signal boost up to +20db
Bass & Treble Controls provide +/- 12db of EQ boost or cut for exceptional tone shaping
On/Off Status LED
9V Battery Powered or optional AC Powered via External Power Jack Input
Input & Output Jacks (Nominal Input -20 db)
SPECIFICATIONS
- Dimensions (W/D/H)
- 2.87" x 4.77" x 2.28" (73mm x 122mm x 58mm)
- Weight
- 0.802lbs (364g) with battery, 0.702lbs (319g) without battery
True Bypass Switching
- Battery Type
- 9VDC (one)
- Power Consumption (Current Draw)
- 9VDC/15mA
- External Power Supply (Not Included)
- WARNING!!! To avoid immediate damage and voiding the warranty, the External Power Supply MUST be 9VDC with aNEGATIVE CENTER plug polarity and a jack plug size of 2.1mm x 5.5mm.
- Input Impedance
- 2M Ohm (500k Ohm minimum)
- Output Impedance
- 10k Ohm
