It is our intention to create a valve amplification device using old school techniques and the best possible components available while remaining true to the tone of the early amplifiers that are sought after today by collectors and professional recording musicians. This amplifier was built entirely by hand by Phil N. Bradbury and uses no printed circuit boards or tag boards in order to give you a true Point-To-Point constructed unit. This 50 watt amplifier uses octal (8-pin) pre amp tubes as opposed to the normal 9 pin pre amp tubes utilized in the bulk of amplifiers built today. Although the 8 pin 6SC7 and 6SL7 pre amp tubes do not have quite the gain of the 9 pin tubes they exhibit exceptional tone and interact with the musicians' tactile feel and attach on the strings in a much more sensitive manner.
- Model
- Custom Build "Lost Boy"
- Serial Number
- LW0950-531
- Electrical Requirements
- 110/120 Volts AC (60 Cycle)
- Pre-Amp Tube
- 6SC7
- Phase Inverter Tubes (PI)
- 6SL7
- Power Tubes
- 6L6GT
- Rectifier Tubes
- 5U4
- Power Transformer
- Hammond: P-T290BX (600 volt/100ma)
- Output Transformer
- Hammond: P-TF22871 (4000 ohm Primary)
- Filter Capacitors
- 1-30uf @ 450v, 2-20uf @450v
- Input 1/Input 2
- Normal Input
- Controls
- Volume for both inputs / Tone for Both Inputs
- Output
- 50 Watts @ 4 ohms
Speaker out, Line Out
- Cabinet
- 16" Tweed Cabinet with Dove Tail Joinery
- Speaker Cabinet
- Tweed with 2 Celestion G12-T75's
