As Dante™ becomes the professional’s choice for AV networking, so the BLACKBOX Recorder delivers a trusted multi-track Dante recorder solution upon which professionals can rely – the BLACKBOX BBR64-DANTE.
With the BBR64-DANTE, users can record and replay up to 64 channels of audio data from a Dante™ network, recording at 44.1kHz and 48kHz directly to Broadcast WAV files on an external USB2 drive. (Higher sample rate recording is also accommodated at a reduced track count.)
The BBR64-DANTE allows hassle-free communication with any of the many hundreds of Dante™-enabled devices now in use worldwide. Designed to support standard network components and switches, it can also record 8 channels of analogue (balanced line in) alongside 56 channels of Dante for capturing audience and ambience.
The BBR64-DANTE will lock to or generate word clock, as well as locking to the incoming Dante audio stream. In addition to the PFL bus providing both hi-resolution metering and headphone monitoring, an additional “mix” feature has been added to the headphone output.
All BLACKBOX Recorders are designed and built to exacting standards with rugged construction and a suite of unique multi-track audio capture features. The choice of professional users, the BBR64-DANTE multi-track Dante recorder is the solution the professional audio industry chooses and trusts. For more information, see below to download the BLACKBOX Recorder brochure, for full information on the entire BLACKBOX range.
- Form Factor
- Rackmount
- Number of Tracks
- 64
- Maximum Simultaneous Tracks
- 64x Recording / 64x Playback
- Display
- 1x Color
- Maximum Sampling Rate
- 96 kHz / 24-Bit
- Number of Microphone Inputs
- No
- Built-In Microphone
- No
- Number of Headphone Mixes
- 1x Master
- Sample Pads
- No
Connectivity
- Analog Audio I/O
-
- 1x DB-25 Balanced 8-Channel Input (AES 59/Tascam Pinout)
- 1x 1/4" TRS Headphone Output
- Phantom Power
- No
- Digital Audio I/O
- No
- Host Connection
- No
- USB (Non-Host)
- 1x USB-A (USB 2.0, External Storage)
- Sync I/O
-
- 1x 1/4" TRS LTC Input
- 1x RCA Coaxial AES/S/PDIF Input
- 1x RCA Coaxial AES/S/PDIF Output
- 1x BNC Word Clock Input or Output
- Network I/O
- 1x RJ45 Dante / Ethernet
- MIDI I/O
- 1x DIN 5-Pin MTC/MMC/Open Loop Input
- Other I/O
- 1x DE-9/DB-9 Sony P2/Control, 1x Mini-DIN 6-Pin Keyboard / PS/2 Input
- Wireless
- Bluetooth (Via Included Adapter)
Performance
- Maximum Input Level
-
- Analog Inputs: +22 dBu for 0 dBFS
- Maximum Output Level
- +22 dBu at 0 dBFS
- SNR
-
- Analog Inputs: 106 dB
- Analog Outputs: 106 dB
- THD+N
-
- Inputs: 96 dB (A-Weighted)
- Outputs: 94 dB (A-Weighted)
Digital Audio
- Audio File Formats
- BWF, WAV
- Sample Rates
- 44.1 / 48 / 88.2 / 96 kHz
- Bit Depths
-
- 16 / 24-Bit (Recording)
- 24-Bit (AD/DA Conversion)
- Sync Sources
- Dante
- Frame Rates Supported
- 23.98 / 24 / 25 / 29.97 / 29.97 DF / 30
- Clocking
- Dante
Audio Storage & Playback
- Supported Media
- SDHC Card, USB Flash Drive, USB Hard Disk Drive
- Media/Memory Card Slot
- No
- File System Support
- FAT32
Compatibility
- Mobile Device Compatibility
- iPad 3rd Gen.
Power
- Power Requirements
- AC/DC Power Adapter (Included)
- DC Input Power
- 9 to 16 VDC
- AC/DC Power Adapter
- 9 to 16 VDC (Included)
- Power Consumption
- 25 W (Maximum)
Physical
- Rackmount Size
- 1 U
- Dimensions
- 16.7 x 5.9 x 1.73" / 425 x 150 x 44 mm
- Weight
- 5.3 lb / 2.4 kg
Packaging Info
- Package Weight
- 7.25 lb
- Box Dimensions (LxWxH)
- 22.6 x 15.7 x 2.8"
