The RM-3 Rackmount 20W Speaker System from Fostex is designed to fit the monitoring needs of space-challenged environments like machine rooms, surveillance operations, and mobile or stationary control rooms. The unit accepts both digital and analog source inputs for compatibility with a wide range of systems, while featuring a THRU output that allows you to send the audio to another destination. Dual anti-magnetic cone speakers provide playback, with the option of using the headphone jack for quiet monitoring.
Left and right channel 26-dot LED meters give you a visual representation of your levels. A mute switch can be programmed for total mute, or to provide a 20 dB attenuation based on your preference.
- Rack mount stereo monitor speaker system with built-in 10W+10W Class-D amplifier and 110x40mm elongated shape speaker units
- Accepts both Analog input (XLR & 1/4" TS phone) and Digital Input (AES/EBU)
- Headphone out for headphone monitoring. When switching from headphone out to speaker out or vice versa, the output signal fades in to avoid unexpected level difference
- Mute switch works as total mute or -20dB attenuation
- Highly visible 26-dot LED meter (L&R) with 4-step brightness adjustment
- Flexible meter setting for both Analog and Digital inputs such as VU+Peak, VU+Peak hold, Peak+Peak hold and VU only
- Reference level (0dB) is selectable between +4dBu and 0dBu
- Audio characteristics can be selected between the conventional VOICE mode and new MU-SIC mode for wider frequency range music source
Speakers
| Built-in Speakers | 110 x 40 mm anti-magnetic cone speakers |
|---|---|
| Impedance | 8 ohms |
| SPL | Output SPL: 84 dB/W (1 m) |
| Frequency Response | 200 Hz to 20 kHz |
Power Amplifier
| Maximum Output | 10 W x 2 |
|---|---|
| Residual Noise | -50 dB or less (DIN AUDIO) |
| Distortion | Distortion Rate: 0.1% or less |
| Digital Input | Connector: XLR-3-31 type Format: IEC 60958 (AES/EBU) Sampling Frequency: 44.1 to 96 kHz |
| Analog Input | Connector: For both XLR/ 1/4" (6.3 mm) TS phone Rated Input Level: XLR (balanced) +4/0 dBV, TS phone (unbalanced): -10/-14 dBV Input Impedance: 10 kOhms or more |
| Digital Through | Connector: XLR-3-31 type |
| Analog Through | Connector: XLR-3-31 type 1/4" (6.3 mm) TS phone |
| Headphones | Connector: 1/4" (6.3 mm) stereo headphone output Adapted Load Impedance: 16 ohms or more Maximum Output: 20 mW+ 20 mW (32 ohms, 1 kHz) |
| Level Meters | Display: 2x 26 dot LED Reference Level: Digital: -20 dBFS Analog: XLR: +4/0 dBu, TS phone:-10/-14 dBV |
General
| Power Consumption | 10 W |
|---|---|
| Power | AC 100 V to 240 V 50/60 Hz |
| Dimensions | 18.9 x 1.7 x 11.2" (482 x 44 x 284 mm), including protruding parts |
| Weight | 7.7 lb (3.5 kg) |
Warranty
This item is sold without the Sound Pure 3-year warranty (used / B-stock / dealer-exempt). Coverage terms for items in this category live in Terms & Conditions, Section 27.
