From Focusrite
Scarlett 18i20 is the ultimate studio hub for demanding project studios. Fully equipped with 18 inputs and 20 outputs, including eight of our most detailed ultra-low-noise mic preamps, line, Hi-Z, and MIDI connections for your drums, vocals, guitars, keys, and synths. Focusrite Control 2 provides flexible routing and mixing options, allowing you to customise 18i20's independent outputs to suit the needs of any recording session. Expand and sync your setup with ADAT, S/PDIF, and Word Clock connections.
Air mode, with Presence and Harmonic Drive, brings the sound of big studio consoles to your recordings, while Auto Gain and Clip Safe ensure you never worry about levels. Low-latency monitoring, A/B speaker switching, and a built-in talkback mic are perfect for serious project studios. The Hitmaker Expansion software bundle has all the tools you need to record, produce, and release your tracks. And the Focusrite Control 2 desktop and mobile apps enable you to remotely control your Scarlett anywhere in the studio.
| Overview | |
|---|---|
| Number of Microphone Preamps | 8 |
| Phantom Power | Yes (Independent) |
| Instrument Inputs | 2 |
| Line Inputs | 8 |
| Air Mode | Yes |
| Auto Gain | Yes |
| Clip Safe | Yes |
| Line Outputs | 10 |
| Headphone Outputs | 2 |
| ADAT Inputs | 2 (up to 8 channels at 96kHz) |
| ADAT Outputs | 2 (up to 8 channels at 96kHz) |
| SPDIF Inputs | 1 |
| SPDIF Outputs | 1 |
| MIDI Inputs | 1 |
| MIDI Outputs | 1 |
| Talkback | Yes |
| Loopback | Yes |
| Connectivity | USB Type-C |
| Protocol | USB 2.0 |
| Form Factor | Desktop/Rack Mountable (1U) |
| Simultaneous I/O | 20x24 (including loopback inputs) |
| A/D Resolution | 24-bit/192kHz |
| Bus Powered | No |
| Dimensions | |
| Height | 46.55mm |
| Width | 259.73mm |
| Depth | 442mm |
| Weight | 3.304kg |
| Supported Sample Rates | |
| 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz | |
| Microphone Inputs | |
| Frequency Response | 20-20kHz ± 0.06dB |
| Dynamic Range | 116dB (A-Weighted) |
| THD+N | -100dB @ 8dB gain |
| Noise EIN | -127dBu (A-Weighted) |
| Maximum Input Level | 16dBu |
| Gain Range | 69dB |
| Impedance | 3kΩ |
| Variable Line Inputs | |
| Frequency Response | 20-20kHz ± 0.05dB |
| Dynamic Range | 115.5dB (A-Weighted) |
| THD+N | -100dB @ 8dB gain |
| Maximum Input Level | 22dBu |
| Gain Range | 69dB |
| Impedance | 24kΩ |
| Fixed Line Inputs | |
| Frequency Response | 20-20kHz ± 0.02dB |
| Dynamic Range | 115.5dB (A-Weighted) |
| THD+N | -106dB |
| Maximum Input Level | 22dBu |
| Impedance | 48kΩ |
| Instrument Inputs | |
| Frequency Response | 20-20kHz ± 0.05dB |
| Dynamic Range | 113dB (A-Weighted) |
| THD+N | -80dB @ 8dB gain |
| Maximum Input Level | 12dBu |
| Gain Range | 62dB |
| Impedance | 1MΩ |
| Line Outputs (Balanced) | |
| Frequency Response | 20-20kHz ± 0.02dB |
| Dynamic Range | 122dB (A-Weighted) |
| THD+N | -112dB |
| Maximum Output Level | 16dBu |
| Impedance | 200Ω |
| Headphone Outputs | |
| Frequency Response | 20-20kHz ± 0.1dB @ 33Ω / 300Ω |
| Dynamic Range | 112dB @ 33Ω 116dB @ 300Ω |
| THD+N | -100dB @ 33Ω -110dB @ 300Ω |
| Maximum Output Level | 5dBu into 33Ω 11dBu into 300Ω |
| Maximum Output Power | 57mW into 33Ω 27mW into 300Ω |
| Impedance | 11Ω |
| Analogue to Digital Converter | |
| THD+N | -110dB |
| Dynamic Range | 120dB (A Weighted) |
| Digital to Analogue Converter | |
| THD+N | -115dB |
| Dynamic Range | 130dB (A-Weighted) |
| Power | |
| External | 30W |
