Input Impedance: 500K ohms
Output Impedance: 470 ohms
Recommended Load Impedance: 10K ohms or greater
Input 1 (mono): ¼ inch mono phone jack
Input 2: ¼ inch mono phone jack
Output 1 (mono): ¼ inch mono phone jack
Output 2: ¼ inch mono phone jack
Expression Pedal: ¼ inch mono phone jack
Aux Switch: ¼ inch stereo phone jack
USB: Type B Socket. Use 2.0 cables only.
MIDI In: Five pin DIN (Female)
MIDI Out/Thru: Five pin DIN (Female)
AC Adapter Jack: US Power Supply included
Power: 9VDC, 500mA, Tip hot (+)
Dimensions: English: 4.8" (H) x 7.5" (W) x 2.12" (D)
Metric: 122 (H) x 190 (W) x 54 (D) mm
Weight: 2.15 lbs, 1kG
