- Directional pattern
-
Supercardioid
- Principle of operation
-
Pressure gradient
- Cartridge type
-
Pre-polarized condenser
- Effective frequency response
-
20 Hz - 20 kHz
- Frequency range, ±2 dB, at 12 cm (4.7 in)
-
100 Hz - 16 kHz. Permanent 3rd order low-cut filter at 80 Hz
- Sensitivity, nominal, ±3 dB at 1 kHz
-
5 mV/Pa; -46 dB re. 1 V/Pa
- Equivalent noise level, A-weighted
-
Typ. 22 dB(A) re. 20 µPa (max. 23 dB(A))
- Total harmonic distortion (THD)
-
< 1% up to 139 dB SPL peak
- Dynamic range
-
Typ. 117 dB
- Max. SPL, peak before clipping
-
160 dB
- Output impedance
-
150 Ω
- Minimum load impedance
-
1 kΩ
- Cable drive capability
-
100 m (328 ft)
- Output balance principle
-
Impedance balancing with Active Drive
- Common mode rejection ratio (CMRR)
-
> 50 dB at 1 kHz
- Power supply (for full performance)
-
48 V Phantom power (±4 V)
- Current consumption
-
Max 2.5 mA
- Connector
-
XLR-3M. Pin 1: shield, Pin 2: signal + phase, Pin 3: - phase
- Weight
-
286 g (10.1 oz)
- Diameter
-
48 mm (1.9 in)
- Capsule diameter
-
19 mm (0.75 in)
- Microphone length
-
188 mm (7.4 in)
- Maximum output voltage, RMS
-
9 Vrms; 19 dBV; 28 dBu
- Polarity
-
+V at pin 2 for positive sound pressure
