Due to popular demand Buzz Audio announces the Series 20 SOC, a Class A version of their well known SOC-1.1 compressor. The Buzz Audio SOC-20 includes additional features suggested by our users including a fully balanced XLR side chain insert point, extra ratio and attack settings and a sidechain high pass filter (for less low frequency compression when used on the mix buss). At the flick of a switch, the SOC-20 converts to a MS (Mid Side) compressor allowing you to compress and/or re-balance the sum and difference signals of a stereo mix. The side chain monitor function allows you to hear the MS signals and the side chain insert send can be used as a MS encoder output. Very very cool!
Features:
- The vivid sound of discrete Class A amplifiers in the signal path
- The lush tone of Lundahl* audio output transformers
- Culmination of 20 years design experience
- Robust chassis construction
- On board linear power supplies - no wall warts!
- Easy to use control layouts
Max Input/Output Level; +23.5dBu (measured with 2k ohm load and 0dB output gain makeup)
Frequency Response; 4Hz to 250kHz (-3dB points with no gain reduction)|
Slew Rate; 20V/uS
Harmonic Distortion;less than 0.008% (measured 100Hz to 10kHz with no gain reduction)
Harmonic Distortion; less than 0.03% (measured 100Hz to 10kHz with 20dB gain reduction, Atk-AUTO, Rel-16)
Residual Output Noise = typically -90dBu, -100dBu A wtg (0dB output gain makeup, 150R source impedance)
Channel to Channel Crosstalk = below noise
Standard Operating Level = +4dBu = 0 VU meter display
Size = 2 Unit 19" rack mount, (482Wx88Hx250D)
Power requirements = 230V/115V selectable on rear, IEC detachable power cable
0dBu reference = 0.775 volts RMS.
Specifications are typical of a production unit and are subject to change without notice.
