Sound Pure's Take
Condition: Used, Excellent
From Boss
NOW, THE LEGENDARY ANALOG DELAY IS BACK WITH A MODERN EDGE
Ever since being discontinued way back in 1984, the BOSS DM-2 Delay pedal has remained highly sought after by players everywhere for its warm, “bucket brigade” analog delay tone. Now, the DM is back! With the Waza Craft DM-2W, the coveted stomp has been reborn with switchable sound modes and greater versatility for today’s music styles. Using 100-percent analog circuitry, the DM-2W’s Standard mode nails the lush sound and 20-300 ms delay range of the original DM-2. Flipping into Custom mode instantly changes the sound character to a cleaner analog tone with over twice the available delay time.
SPECIFICATIONS
Nominal Input Level-20 dBu
Input Impedance 1 M ohm
Nominal Output Level-20 dBu
Output Impedance 1 k ohm
Recommended Load Impedance 10 k ohms or greater
- Delay Time - Standard Mode
- 20 ms to 300 ms
- Custom Mode
- 40 ms to 800 ms
Controls
Pedal switch
REPEAT RATE knob
INTENSITY knob
ECHO knob
Mode switch
Indicator
CHECK indicator (Serves also as battery check indicator)
Connectors
- INPUT jack
- 1/4-inch phone type
- OUTPUT jack
- 1/4-inch phone type
- DIRECT OUT jack
- 1/4-inch phone type
- RATE jack
- 1/4-inch TRS phone type
DC IN jack
Power Supply Alkaline battery (9 V, 6LR61) or Carbon-zinc battery (9 V, 6F22)
- AC adaptor (PSA series
- sold separately)
Current Draw 35 mA
Expected battery life under continuous use (These figures will vary depending on the actual conditions of use.
- )Alkaline
- Approx. 15 hours
- Carbon
- Approx. 5 hoursAccessoriesLeaflet ("USING THE UNIT SAFELY," "IMPORTANT NOTES," and "Information")
Alkaline battery (9 V, 6LR61)Options (sold separately)AC adaptor: PSA series
- Expression pedal
- Roland EV-5
SIZE AND WEIGHT
Width 73 mm, 2-7/8 inches
Depth 129 mm, 5-1/8 inches
Height 59 mm, 2-3/8 inches
Weight 460 g, 1 lb 1 oz
Warranty
This item is sold without the Sound Pure 3-year warranty (used / B-stock / dealer-exempt). Coverage terms for items in this category live in Terms & Conditions, Section 27.
Returns
Try Before You Buy: take it home, commit only when it's right. Program details →
