From Avid
HD I/O is the next-generation flagship audio interface for Pro Tools|HD, delivering higher fidelity audio and lower latency performance than its predecessor, the 192 I/O. HD I/O offers 16 channels of I/O, and comes in one of three configurations to provide ultimate flexibility:
1. 8x8x8: 8 analog I/O and 8 digital I/O
2. 16 x 16 analog
3. 16 x 16 digital
HD I/O also comes with a newly designed high quality soft-knee analog limiter feature, Curv, which catches fast transients and allows for tracking hotter signals. HD I/O moves beyond the market competition by delivering best-in-class digital audio conversion and clocking that integrates into Pro Tools HD software and offering the most flexible I/O arrangement.
16 total audio paths
- Line-level I/O (DSUB)
- 8 ch.
- AES I/O (DSUB)
- 8 ch.
- ADAT/SUMX I/O
- 8 ch. @ 48k, 4 ch. @ 96k, 2 ch. @ 192k
- TDIF I/O
- 8 ch.
- AES I/O (enclosed)
- 2 ch.
- S/PDIF I/O (enclosed)
- 2 ch.
- ADAT/SMUX/Optical S/PDIF I/O (enclosed)
- 8 ch. @ 48k, 4 ch. @ 96k, 2 ch. @ 192k
Curv soft knee limiter
SRC on AES, and TDIF DSUB inputs
- Word Clock I/O
- 2
- Loop Sync I/O
- 2
- Input/output cal trims
- one set
- DigiLink Mini Connector
- Primary and Expansion
One free expansion slot available for ADC, DAC or Digital card
