From Avedis Audio
The Avedis Audio MD7 addresses the features needed in op-amp based preamps and, more importantly, with a very musical sound without the conventional hard sounding and mid-forward units which are not suitable for today’s digital recordings.
Features
- Gain range from 0dB – 64dB in 4dB steps for recall-ability
- Input Trim control for fine control of gain
- TransDrive™ circuitry for slight saturation at peaks
- Utilizes the discrete 1122 op-amp known for depth and resolution
- All discrete design with Class A buffer amplifier
- Wide bandwidth, high headroom, very low noise
- NO PAD, NO IC’s, and NO Surface Mount Components
- Line Input to interface with DAW’s
- Phase reverse, and filtered 48V phantom power
- High Pass Filter using a gentle slope for natural bass roll-off (-3dB @ 80Hz)
- 10 Meg-ohm high impedance DI input great for all instrument pickups
- SEND feature to run signal through stomp boxes for variety of effects
- Frequency Response: <10Hz to -3dB at 75kHz
- Input Impedance: ≅1500 ohms
- Output Impedance: <75 ohms
- Common Mode Rejection Ratio: >123dB min @ 60Hz
- Maximum Output Level: +28.8 dBu @ 100KΩ, +27.4 dBu @ 600Ω
- Power Requirements: ±16 vdc @ 35mA per rail
- Gain Voltage: 0 to 22 Volts
- Gain dB: 0 to 64.7 dB
- Equivalent Input Noise: −114 dBu; Unweighted 300kHz bandwidth
- Weight: 2.6 lbs
