Acoustic Image Clarus SL-R Head #6L0161 - USED  From Acoustic Image

1 Channel amp with effects!

Close

Buy Pre-owned from Sound Pure with Absolute Confidence

Sound Pure's dedication to pre-owned products is unprecedented in the industry. We are a small team of dedicated experts that buys, trades, and consigns. We are trusted by customers all over the world. Our curated collection, is thoroughly tested and inspected by some of the best in the business. Our inventory is constantly changing, ever-evolving, with some items sold before reaching the website. Looking for something specific? Have questions about this product's condition or history? Want more photos, or to simply chat with an expert who's had his hands on this actual piece? Contact us now.
Our Current Used/Vintage Collection »

Sound Pure's Consignment Program »

Luthier Certification for Used Instruments »

Acoustic Image Amps

"Gone, Baby, Gone"

This one is sold. Don't miss the next one. Some things never even make it to the site so stay up to date on our used collection.

We get in many oddities, rare and vintage products, most of which go fast. If you're on the hunt for something specific, something unique, or something priced right, let us notify you on our used collection before the items even hit the site.

Want to know if one lands?

Notify Me

Want to discuss what's coming?

What We Think

Condition: Used, Excellent

Manufacturer's Description from Acoustic Image

Extended frequency range, high fidelity sound



Light weight (<2.5 lbs.), small size (2.1x7.2x7.4 inches)



LoZ and HiZ 1/4 inch inputs for piezo pickup optimization



Input and Master level controls



Four band EQ I



Sweepable low cut filter



Effects loop



Selectable reverb and delay effects with level and rate controls



Direct out with selectable 10 dB pad, pre/post switch and ground lift



Mute switch



Selectable internal jumper options for gain and limiter



High fidelity, low noise operation: 110 dB SNR at direct out



Automatic voltage switching for universal AC mains operation



650 Watt output at 4 ohms (music power)



Dual speaker outputs with speakon connectors

Acoustic Image Amps

About Manufacturer

Although Acoustic Image is a relatively young company, it is owned and operated by people with decades of experience in the professional music and sound industry. They're engineers (and, like their customers they're also musicians) who insist upon superior sound quality and reliable performance from our audio equipment. Acoustic Image was founded because they were never satisfied with the products available for the working musician. If you play guitar or bass, violin, keyboard, a woodwind or even a brass instrument, or you are a vocalist, they've got a sound reinforcement product designed with you in mind. Great product designs go far beyond having the right knobs in the right places. Acoustic Image’s company charter is to design and build unique, innovative, and functional audio products... there is nothing "me too" about what they do. In essence, they have merged advanced acoustic design and switching amplifier technology to create incredibly compact, ultra-lightweight products offering highly accurate sound for serious musicians. Ultimately, their pledge to you is for quality... to build a well-constructed reliable audio product that serves you well night after night, year after year. And, quite frankly, they believe the best way to do that is to design and manufacture each and every Acoustic Image product in the U.S.A. Their Technology Applying "musical thinking outside the box", they have taken a different approach to the technology of musical instrument amplification in order to improve the performance and portability of combo amps for the working musician. So, what's so unique about their products? There are three key differences: 1) The use of downfiring low frequency drivers 2) The use of switching power amplifiers and switching power supplies instead of the traditional linear designs 3) The use of unique enclosure shapes to improve portability and sonic performance Each of these differences provides an improvement in the performance of their products. Here's how: The downfiring woofer makes a small driver sound bigger and allows a smaller enclosure for a given driver size. Omnidirectional output produces a more natural and more transparent sound, and means you are more easily heard on the bandstand. The switching (Class D) amplifier design is smaller and more efficient than traditional linear amps. It has less weight because there are no heatsinks or cooling fans and it has a unique "warm" sound (unlike traditional solid state amps) because its output stage is radically different from traditional amps. The switching power supply eliminates large bulky power transformers with a resulting dramatic decrease in weight. With their unique enclosure shapes, form follows function. A cylinder is an inherently stiffer enclosure. And no resonances in the enclosure walls means less coloration in the sound. Also, the stiffer enclosure allows the walls to be thinner and lighter in weight. Add to that the use of acoustically inert polymer materials and the cabinet becomes ultra light. We don't use these new technologies to “be different.” They use them because they make their products better. It all adds up to a more portable, better sounding products. Because of their small size and high sound quality, they virtually disappear on stage, leaving the sound of the instrument being amplified, only louder.

Specifications

Model: Clarus SL-R



- System -



Frequency Response: 30 Hz-20 kHz (±0.5 dB)



Signal to Noise Ratio: >110 dB at direct out



AC Power: 100V to 240V, 50/60 Hz, automatically switched



Size: 2.1" x 7.2" x 7.4"



Weight: 2 lbs 10 oz



- Preamp -



Instrument Input: 1 Mohm or 10 Mohm, ¼ inch jack



Direct Out: +4 dB, balanced, XLR connector, ground lift, pre/post EQ selector, switchable 10 dB pad



Effects Loop: Parallel Type



Low Control: Shelving type, ±12 dB at 30 Hz



Low Mid Control: ±12 dB at 250 Hz



Hi Mid Control: ±12 dB at 1200 Hz



Treble Control: Shelving type, ±15 dB at 10 kHz



Low Cut Filter: -12 dB/octave sweepable from 30 to 180 Hz



- Effects -



Type: 24 bit digital with 3 programs



Programs: Reverb with variable decay time, Delay/Reverb with variable delay time, Delay with variable delay time, All have variable wet/dry mix and “pseudo stereo” capability



- Power Amp -



Topology: Class D (PWM)



Switching Frequency: 500 kHz



Output Power 8 Ohm: 300W rms continuous, 350W rms music (40% duty cycle), 500W peak transient



Output Power 4 Ohm: 500W rms continuous, 650W rms music (40% duty cycle), 1000W peak transient



External Speaker Out: Speakon type (pole 1), 2ohm min load
