From Grace Design
The Lunatec V2 was another on of our "it pays to listen" stories. We originally built a run of DC powered portable stereo mic preamplifiers way back in the early 90's, before we were even Grace Design. Well, the 50 preamps became the subject of a great cult legend in the live concert taping world. At the urging of a taper colleague and after further investigation into the truth of the legend, we decided to make this a bona fide offering. Chances are, if you're at a rock concert that allows taping, there's at least one V2 passing signal. When we revised this as the Lunatec V3, the legend continued to grow, and now the little blue front panels are everywhere live music is being recorded.
EIN
- @60dB gain <130dB
FREQUENCY RESPONSE
- +/- 3dB @60dB gain: 6Hz-250kHz
THD+N
- +20dBu out @20dB gain 0.0011%
- +20dBu out @40dB gain 0.0011%
- +20dBu out @60dB gain 0.0046%
INTERMODULATION DISTORTION
- @40dB gain +25dBu out <.0025%
NOISE - REFERRED TO INPUT
- @60dB gain 50 Ohm source <-130dB
PHASE DEVIATION
- 50-20Khz <8°
CROSSTALK
- Either Channel -109dB
CMRR
- @60dB gain, 3.5Vcm, 1KHz 65dB
- @60dB gain, 3.5Vcm, 10KHz 96dB
- Output CMRR 55dB
MAXIMUM OUTPUT LEVEL
- Balanced +27dBu
- Unbalanced +21dBu
IMPEDANCE
- Input 1600Ohms
- Output 150Ohms
- Minimum Load Impedance 600Ohms
WEIGHT
- 2.4lbs
DIMENSIONS
- L5.5" x W8.3" x H1.6"
POWER CONSUMPTION
- 500mA DC 6-12V
