From Microtech Gefell
The studio condenser microphone M 1030 combines modern large diaphragm capsule technology with the latest in semiconductor circuit topology. The size of the microphone housing is optimized with regard to the expectations of a large diaphragm microphone for studio applications. The microphone is specifically designed to meet the needs of professional and semiprofessional users who demand the highest performance. The microphones are ideally suited for universal miking applications in broadcast and sound studios. Applications include vocalists, announcers, dialog pickup and as spot microphones for recording guitars, keyboard, percussion, wind and string instruments.
The electronic impedance converter uses a perfected circuit topology. This design reduces the noise floor to an extremely low level while also raising the maximum output capability. As a result, these microphones have a clean, distortion free sound over anextremely wide dynamic range. RFI susceptibility is very low.
Features
♦ Extreme dynamic range
♦ Noise floor 7 dB-A
♦ Large diaphragm capsule
♦ Polar pattern
♦ Universal applications
♦ Advanced circuit design
♦ Transformerless output
♦ Internal elastic suspension
♦ Optical ready indicator
Polar pattern: cardioid
Acoustic operating principle: pressure gradient transducer
Frequency range: 20 Hz to 20.000 Hz
Sensitivity at 1 kHz: 21 mV/PA
Output impedance: 100 Ohm
Noise level: CCIR 468-4: 13 dB
DIN EN 60268-4: 7 dB-A
Signal-to-noise ratio: CCIR weighted: 81 dB
A-weighted: 87 dB
SPL for THD 0,5 %: 142 dB
Max. output level: R = 1 kOhm 17 dBu
R = 10 kOhm 18 dBu
Dynamic range: 135 dB
Current consumption: 3,6 mA
Output connector: XLR3M
Weight: 355 g
Length: 145 mm
Diameter: 66 mm
Surface: satin nickel
