2-way Active Nearfield, 6.9" woofer & 1.1 softdome tweeter , 1 Master and 1 Slave, AIR Remote and AIR Software
AIR6 is developed for both stereo and multichannel monitoring in any demanding environment. Post production facilities and music recording and mixing studios will benefit greatly from the technology and clear monitoring that AIR6 provides. Installing an AIR6 system will be equally advantageous when it comes to small film editing rooms and OB vans.
DSP room adaption allows for perfect customization for any room construction and its inter-monitor level calibration feature ensures consistent levels in all sessions.
AIR6 is developed for both stereo and multichannel monitoring in any demanding environment including:
- Post Production
- Music Recording and Mixing
- Film Editing (smaller rooms)
- DVD authoring and Mastering
- 5.1 Production (Audio or Audio for pictures)
- Broadcast
- Edit suites
Typical listening distance 1.2-2m / 4-7ft
Typical room size 50-100m3 / 1600-3500ft3
The Vision A world where there is no difference between real / live sound and sound reproduced by a loudspeaker. A world where audio engineers, consumers, music-lovers and film viewers expects 100% accurate reproduction of sound - the perfect illusion with all the transparency, details and imaging we know from the real world. This is the vision of Dynaudio Acoustics - a world where you trust what you hear without even thinking about loudspeakers. The Mission Develop, innovate and manufacture state of the art monitors that can be trusted 100% by audio engineers and artists. Everything we do is centered at the artists that work with audio and demands transparent and accurate reproduction of sound - our customers. After all, it is the very same artists that in return give us productions and art that make it all worthwhile. We constantly challenge ourselves and innovate in search of further improvement and perfection of sound reproduction. Our customers Include some of the most demanding studios, engineers, producers and production environments throughout the world. We are proud of our customers and what they achieve. The Owl The great horned owl is known for its super hearing, sight for details, intelligence and precise judgement. Horned owls are active during night. They rely on and trust their ears 100% when navigating through the big woods searching for food. It is said that the great horned owl while in the air can hear small targets moving on the ground - they can also hear the exact distance and direction to the sound source. The ability to focus on, hear and judge the detail while working with the big picture is what makes working with audio an art. Engineers, like the great horned owl, must trust what they hear. Like the great horned owl, we believe that engineers deserve the freedom to navigate and judge the sound-scapes relying on their ears. That is the reason we have placed the Great Horned Owl in the centre of our Logo and that is the reason we build monitors that speak the truth - not more, not less.
System 2 way active NearField Monitor
Total Frequency response 40 Hz - 22 kHz / 33 Hz - 22 kHz : +/- 3dB
Max SPL 1m, pair (IEC short term) 128 dB peak / 128 dB peak
Max SPL 2m, 5.1 (IEC short term) 126 dB peak / 126 dB peak (no LFE )
Precision of Monitor matching +/- 0.2 dB
Port tuning frequency 45 Hz
Internal Cabinet volume 12.1 liters
Bass principle Bass reflex
Crossover frequency 2150 Hz (DSP generated)
Crossover slope 24dB/oct (Linkwitz Riley, DSP generated)
Tweeter Esotec 28mm / 1.1" soft dome, rear chamber, magnetic fluid, 4 mm die-cast alu front, pure aluwire voice coil
Woofer 175mm / 6.5" one-piece molded polyprop dome, 75mm / 3" pure alu voice coil
Mains voltage 100 to 240 VAC, 50 to 60 Hz (auto-select)
Power consumtion Idle: 50W / Max: 375W
Finish - Amp: Black anodized alu back plate Cabinet Dark gray MDF baffle, Silver foil
Weight Depth incl. amp & driver: 382mm, 9.8kg
Amplifier - Tweeter Separate 200W PWM amp
Woofer Separate 200W PWM amp
System sample rates -
Internal sample rate 96 kHz
External sample rate 31-97 kHz
AIR Masters only -
I/O Connectors XLR (2 channels AES/EBU in) 3 x RJ 45 proprietary TC Link
Formats AES/EBU (24 bit)
Word clock input BNC, 75ohm, 0.6-10 Vpp
Display 2 x 16 character dot matrix Operation Menu system / Four bottoms
Analog Input options - Input connectors XLR balanced (pin 2+, pin 3-)
Impedance 10/3 kohm (Balanced/Unbalanced)
Selectable Full scale Input level +9, +15, +21, +27 dBu
Dynamic range > 113 dB typ.
(Unwighted), BW: 20-22kHz
THD+N < -105 dB typ. @ 1 kHz, -3 dBFS
Crosstalk < -120 dB, 20Hz to 20kHz
A to D Conversion 24 bit (dual bit delta sigma sampling @ 4.1/5.6/6.1/6.1 MHz)
I/O Connectors 2 x RJ 45 proprietary TC Link
EMC - Complies with EN 55103-1 and EN 55103-2, FCC part 15 class B, CISPR 22 class B
Safety - Certified to IEC 60065, EN 60065, UL 6500, & CSA E60065, CSA File# LR 108093
Enviroment - Operating temperature 32? F to 122? F (0? C to 50? C)
Storage temperature -22? F to 167? F (-30? C to 70? C)
Humidity Max 90% non-condensing
Warranty - Parts & Labor 1 year
