From WesAudio
INNOVATIVE DESGIN with fully ANALOG CIRCUIT
_PROMETHEUS is fully analog equalizer with +24 dBu of headroom.
Passive EQ
Low section with boost and cut, frequencies: 20, 30, 60, 100, 120, 250 Hz.
High boost section with following frequencies – 2, 3, 4, 5, 8, 10, 12, 16 kHz.
High cut section with following frequencies – 4, 8, 12, 20 kHz.
STEREO / DUAL MONO / MID-SIDE operation modes
_PROMETHEUS can work in 3 different modes, including MS, which makes it perfect solution for multiple applications!
OUTPUT CONTROL
POST-EQ OUTPUT control for better flexibility!
HARDWARE A/B
Even using _PROMETHEUS as pure analog signal processor you can easily switch between two parallel settings with a magic of a simple button.
THD – ADD COLOR TO YOUR MIXES
THD stands for “Total harmonic distortion” and it allows to saturate your signal with beautiful analog color.
FLEXIBLE DAW / LIVE PLUG-IN control for instant recall
Stereo plugin which handles all modes of operation – Stereo/Dual Mono/Mid-Side
Mono plugin where two separate instances can connect to same hardware managing each channel separately
IN/OUT metering with clip detection
Plugin comes in AAX/AAX DSP/VST3/VST2/AU
Features
♦ +24dBu of headroom
♦ Stereo / Dual mono / Mid/Side operation mode
♦ Passive equalizer (Pultec-style) design based on inductors
♦ Low frequency boost/cut – 20, 30, 60, 100, 120, 250 Hz.
♦ High frequency boost – 2, 3, 4, 5, 8, 10, 12, 16 kHz.
♦ High frequency cut – 4, 8, 12, 20 KHZ.
♦ Proprietary THD implementation
♦ Flexible DAW/Live plug-in control for instant recall
♦ 6 touch sensitive encoders allows to record automation
♦ True bypass
♦ In and OUT metering with clip detection
♦ A/B compare feature
Frequency response: 10Hz-150kHz (-2dB)
THD+N < 0.01% (1kHz,0dBu)
Input impedance: 10kohm
Output impedance: <100ohm
Max signal level: +24dBu
Crosstalk:< -100dB
THD (MID switch): 1%
THD (HIGH switch): 2.5%
Power consumption: 70mA per rail
Dimensions : 76x133x158mm
Warranty: 2 years
