Item selected is discontinued (details below). Related products available now:
WesAudio DUE-PRE 500-Series Preamp From WesAudio
Two preamp styles in one! British classic tone or American vintage at the touch of a button
Manufacturer's Description from WesAudio
Preamp circuit is switchable between two amps: RED and GREEN.
RED mode is a British classic style preamp (1073) and GREEN is an American vintage style preamp (discrete opamp). Both preamps have unique sonic textures known as a best classical sound preamps.
Carnhill transformers are responsible for matching impedance and de/symmetrization circuits. The preamp is loaded with two PADs: IN 20dB PAD and OUT 8dB PAD which allows the saturation of both preamp and output transformer.
Additionally, DUE-PRE has front input XLR Combo socket which can be used in both ways: as a mic input and as an instrumental input. Instrumental input is a high impedance input of which signal feeds input transformer through FET transistor. The module can draw up to 5W of power.
About Manufacturer
WesAudio is a manufacturer of professional audio equipment. By utilizing the latest technology, introducing unique design solutions as well as using measuring devices such as Audio Precision, Agilent, Tektronix, Fluke, we are proud to present the first devices available in the sales offer of WesAudio.We strive to assure that our products are of high quality and precision. We provide full warranty and service of all the equipment available for sale.
Specifications
- – High-quality Grayhill gain switch
- – 64dB of gain (preamps are matched with 0.5dB accuracy)
- –Canrhillin/out transformers
- – 20dB input PAD
- – 8dB output PAD (allowing saturation of both preamp and transformer)
- – Polarity Reverse switch
- – +48V phantom power
- –ForntautosenseXLR mic
- – Hiz Fet DI front input (the signal passes through the input transformer)
- – LED VU meter
Electrical specifications:
- – Input impedance: 1200ohm
- – Output impedance: 600ohm
- – Max. output level: RED (+27dBu); GREEN (+23dBu)
- – min THD ratio: 0.005%
- – Total gain: 64dB
- – Power: up to 5W
