• Multi-function delay with stereo in and out.
• Midi control.
• Five custom programs. Digital, Mod, Vintage, Dual, Reverse.
• Three subdivisions: Quarter, Eighth and Dotted Eighth.
• Up to nine on-board presets or up to 128 via midi.
• Each program can be extensively modified with its own modulation, tone control and age via the tweak knob.
• Soften echo attack with the attack knob.
• Bypass switch features momentary function. Press and hold bypass to ramp up repeats. • 9-volt DC, Center Negative, 300mA minimum.
• Made in USA.
ALGORITHMS
Digital - The Digital delay algorithm offers a clean and crystal-clear delay that is perfect for rhythmic guitar parts where ultra-defined echoes are desired.
Mod - The Mod delay algorithm has unique modulation LFOs applied to the repeats that are random and run at multiple rates to create unpredictable pitch modulation.
Vint - The Vintage algorithm allows for bucket brigade and tape delay inspired tones to be achieved with different types of filtering applied to the repeats. Use the tone knob at lower settings for bucket bridge type filtering and at higher settings for tape type filtering.
Dual - 1) Mono: The Dual algorithm employs multiple delay taps creating more rhythmic sounding delays. 2) Stereo: If both outputs are connected for stereo use, the repeats from the RIGHT delay channel will “ping-pong” or pan, back and forth between both left and right outputs. The following describes the division combinations for each switch position.
Reverse - The Reverse algorithm reads the delay memory backwards creating a unique delay repeat character known as reverse delay.
