Two Notes Torpedo Studio  From Two Notes

Two Notes' Torpedo Studio is not only the most advanced digital loadbox on the market, but is also the simplest way to capture the sound of your amp for recording or live applications!

Two Notes Audio Engineering

$1,399.99

"Experience the Difference"

Sound Pure's 3-Year Warranty

Close
Our Free 3-Year Warranty!
In addition to the standard included manufacturer warranty, virtually all new products carry our exclusive, industry-leading, absolutely free, Sound Pure 3-Year Warranty, which includes PARTS & LABOR. This high-value perk is our way of providing the ultimate in added value to enhance the unique personal touch our small, dedicated team contributes to each purchase.
Learn more »

Lifetime Support

Close
Free Lifetime Technical Support!
Our small team of dedicated experts is here to help the original purchaser for the lifetime of the product. Why? Because we care about building real relationships with our customers for life and stand behind every product we sell.

Free Shipping

Close
This Product Ships Free!
Products ship from our well-located, climate- and humidity-controlled warehouse absolutely free (inside the continental USA). Low-cost international shipping options exist for most products.
Contact us for details »

No Sales Tax Outside North Carolina

Contact us for up-to-date delivery estimate.
Payments as low as $31/mo.

Two notes Torpedo Studio - Steve Stevens

Legendary guitarist Steve Stevens takes us through how he used the brand new Torpedo Studio.

  • Signal Chain
    • Two Notes Torpedo Studio

Manufacturer's Description from Two Notes

The Torpedo Studio is the next generation of the world-acclaimed VB-101, this is the pinnacle of speaker and miking simulation– the ultimate loadbox! Its new features notably include a new loadbox with increased admissible power, a switchable impedance (4, 8, or 16 Ohms), and the possibility to choose between resistive and reactive loadbox.

The concept:

You love the sound of your amplifier pushed right to the magic sweet spot where the best tones are. Until now, the only available option was blasting your sound through a 4×12″ to properly excite a microphone. Enter Torpedo, the simplest and most realistic way to get your sound to your audience. Use the amp you love!

Everything that makes a real amp rule over all the other alternatives is retained. You can even record silently late at night ! Gone is the backache from the loadout, complaints from neighbours, venue staff or even bandmates and the frustration of not being able to sound at one’s best trying to reduce the volume.

Exclusive Torpedo technology:

Highly realistic speaker simulation is achieved by use of convolution. Two notes started from that technology and brought it much further, to accurately reproduce the characteristics of the whole miking chain (speaker, microphone, preamplifier, studio room acoustic).

Many parameters influence the sound of your guitar or bass rig when it comes to recording. Taking good care of the cabinet selection and miking will dramatically improve the sound of your takes. The Torpedo simulation reproduces the tiniest variations of a cabinet behaviour such as frequency response and distortion. Move the microphone in the virtual studio room thanks to the Torpedo IR synthesis, control the phase with the Variphi: all the settings you need to achieve great recordings are here.

Loadbox with adjustable impedance:

Use your amplifier without speaker cabinet thanks to the loadbox of the Torpedo Studio. Its adjustable impedance of 4, 8 or 16 Ohms and its high admissible power (150W) makes it suitable for any amp. The reactive impedance faithfully imitates a speaker, allowing the amp to work exactly as if it was connected to a speaker cabinet.

Dual mono/stereo miking:

combined simulation of 2 cabinets + 2 microphones for optimal mixing. Position two different microphones before your speaker, or before two different speakers. Mix the two simulations to send them to the stereo outputs.

Post-FX section:

when recoding guitars and basses it is common to apply a few effects to shape the sound before it is sent to the PA or recorder. The Studio comes with a powerful semi-parametric EQ, and exciter, a compressor and a wonderful reverb.

Control your Torpedo & access the Two notes Boutique:

With its clear and intuitive interface, Torpedo Remote will give you access to all parameters on your Torpedo, including loading and saving presets, loading new IRs, and updating the unit’s firmware. You can pick any speaker cabinets from the Two notes Store, preview them on your own tracks in real time, and choose to buy the ones you prefer.

Connections:

Connect your guitar or bass and effects to your amplifier as you are used to, then connect your amp to the Torpedo Studio instead of a speaker cabinet. The Torpedo Studio can then be connected to a mixing board and PA, or to a sound interface for recording, in the studio or at home. You can also use headphones for direct monitoring. An optional speaker cabinet can be connected to the Thru output.

You can also use the Torpedo Studio with a preamplifier, or as an external effect processor in a studio or home studio environment. The large choice of available analog or digital inputs and outputs allows the Torpedo Studio to work in any situation.
Two Notes Audio Engineering

Specifications

Connectivity:

  • Amplifier input: Jack 6.35 mm (1/4) unbalanced (TS, Tip/Sleeve), to connect the speaker output of your tube or solid state amplifier
  • Speaker Thru: Jack 6.35mm (1/4”) unbalanced (TS), to connect an optional cabinet instead of using the internal loadbox)
  • Line inputs: 2 x Combo XLR – Jack 6.35 mm (1/4”) balanced (TRS)/unbalanced (TS)
  • Line outputs: 2 x XLR balanced
  • Headphones output: Jack 6.35 mm (1/4”) balanced (TRS) stereo
  • Digital inputs: AES & S/PDIF 2 channels input
  • Digital outputs: AES & S/PDIF 2 channels output
  • Wordclock sync BNC
  • MIDI In, Out/Thru
  • USB port
MIDI:

The Torpedo Studio is fully controllable via MIDI. Program Changes are used to change presets. Control Changes are used to control the parameters of the Torpedo Studio.

Loadbox:

Reactive or Resistive load (relay),
Nominal impedance: 4 or 8 or 16 Ohms (switch)
Maximum admissible power: 150 W (200 Watt peak)
Cooled by temperature-controlled fan

Inputs/Outputs:

Speaker Input: Jack 6.35 mm (1/4″) unbalanced (TS, Tip/Sleeve)
Speaker Thru: Jack 6.35mm (1/4″) unbalanced (TS)
Line Inputs: 2 X Combo XLR – Jack 6.35 mm (1/4″) balanced (TRS)/unbalanced (TS) – Maximum level: 8,7 dBu – Impedance: 20 kOhms
Line Outputs: 2 x XLR balanced – Maximum level: 11 dBu – Impedance : 600 Ohms
Phones: Jack 6.35mm stereo (TRS)

AES/EBU numeric Input/Output
S/PDIF numeric numeric Input/Output
MIDI Input/Output
USB Connection

Audio Performance:

ADC (input):
Sampling frequency: 192 kHz
Resolution: 24 bits
Noise level: -111 dB (A-weighted)
THD: 0.0026%
Stereo crosstalk: -109 dB

DAC (output):
Sampling frequency: 192 kHz
Resolution: 24 bits
Noise levelt: -109 dB (A-weighted)
THD: 0.0008%
Stereo crosstalk: -106 dB

13Hz- 45 kHz

AES/EBU and S/PDIF to 96 kHz

Internal synchronization , AES/SPDIF ou Wordclock

Latency: (mode Normal) 5.063 ms, (mode Low) 3.064 ms (Line Input à Line Output)

The Torpedo Studio comes with a selection of 50 Two notes cabinets and much more!
