From SPL
Analog inputs & outputs; XLR (balanced)
- Maximum input gain 21 dBu
- Input impedance 22 kΩ
- Maximum output gain 21 dBu
- Output impedance < 600 Ω
- Common mode rejection (1 kHz) > 82 dB
- Frequency range (-3 dB) 10 Hz – 100 kHz
- THD + N (0 dBu, 10 Hz – 22 kHz) -90 dB
- Noise (A-weighted) -97 dB
- Dynamic range 118 dB
Internal Linear Power Supply with Toroidal Transformer
- Operating voltage for analog audio +/- 15 V
- Operating voltage for relays and LEDs + 12 V
Mains Power Supply
- Mains voltage (selectable) 230 V AC / 50; 115 V AC / 60 Hz
- Fuse for 230 VT 200 mA
- Fuse for 115 VT 400 mA
- Power consumptionmax. 15 W
Dimensions & Weight
- W x H x D (width x height x depth) 482 x 44 x 237 mm; 19 x 1.73 x 9.33 inch
- Unit weight 3,3 kg7,27 lbs
- Shipping weight (incl. packaging) 4,45 kg; 9,81 lbs
