From Joemeek
| Input impedances: | Mic: 1.2kohm; Line: 20kohm |
|---|---|
| Pre-amp overall gain: | 0dB to 60dB |
| Common mode rejection: | 70dB |
| Equivalent input noise: | -128.5dBu (unweighted) |
| Distortion: | 0.001% (below Compressor threshold) |
| Frequency response: | 10Hz to 70kHz (-3dB) |
| Maximum input before clipping: | Mic: +19.5dBu; Line: +44.5dBu |
| Headroom before clipping: | +19.5dBu |
| Compressor threshold: | -6dBu to +20dBu (variable) |
| Compressor ratio: | 5:1 (typical) |
| Compressor attack time: | 1 msec to 100 msec (adaptive) |
| Compressor release time: | 0.1 sec to 3 sec (adaptive) |
| Nominal output levels: | +4dBu/-10dBv |
| Output impedance: | 75ohm |
| Output Level switch: | 12dB attenuation |
| Noise Floor: | -85dBu (typical, with ~40dB mic gain) |
| VU Meter: | 8 segment bargraph |
| Power supply: | 12V ac mains adaptor |
| Power consumption: | 12W |
| Mechanical: | 220W x 44H x 180D (overall) |
| Weight: | 1 kilo |
| EQ Boost and Cut: | +/-15dB (zero phase-shift bell response) |
| LF Frequency : | 80Hz fixed |
| MID Frequency : | 300Hz to 5kHz variable |
| HF Frequency : | 12kHz fixed |
