Gefell UM 92.1 S Vintage Microphone  From Gefell

Large Diaphragm, Multi-Pattern Vacuum Tube Microphone

Microtech Gefell

$3,175.15

Retail:  $4,300.00

"Experience the Difference"

Sound Pure's 3-Year Warranty

Close
Our Free 3-Year Warranty!
In addition to the standard included manufacturer warranty, virtually all new products carry our exclusive, industry-leading, absolutely free, Sound Pure 3-Year Warranty, which includes PARTS & LABOR. This high-value perk is our way of providing the ultimate in added value to enhance the unique personal touch our small, dedicated team contributes to each purchase.
Learn more »

Lifetime Support

Close
Free Lifetime Technical Support!
Our small team of dedicated experts is here to help the original purchaser for the lifetime of the product. Why? Because we care about building real relationships with our customers for life and stand behind every product we sell.

Free Shipping

Close
This Product Ships Free!
Products ship from our well-located, climate- and humidity-controlled warehouse absolutely free (inside the continental USA). Low-cost international shipping options exist for most products.
Contact us for details »

No Sales Tax Outside North Carolina

Contact us for up-to-date delivery estimate.
Payments as low as $72/mo.

Want a lower price?
Call or email us!
888-528-9703
sales@soundpure.com

Manufacturer's Description from Gefell

The Gefell UM92.1S is a 'vintage' large-diaphragm multi-pattern tube microphone. It is equipped with the original M7 capsule. This pressure gradient transducer features a dual-membrane, gold evaporated PVC capsule that is still hand-made in the Gefell factory following the 75-year tradition. The Gefell UM92.1S is the choice for those that want the true sound and character of the original Neumann-Gefell UM57 with the added benefit of improved reliability and lower noise. The UM92 exhibits high sensitivity, excellent signal-to-noise ratio and it has the full sound, tube warmth, and character that are favored by singers and soloists.



Design Features

The Gefell UM92.1S is a multi-pattern microphone with switchable back-diaphragm voltage on the power supply for choice of figure-8, cardioid and omni-directional patterns. It is also available in a cardioid-only version called the M92.1S.

As with all Gefell microphones, mechanical and electrical attributes have been optimized for performance. Careful attention to reducing 'vortex' around the mic and capsule is achieved by mounting the M7 capsule on triangulated pedestal. This has the benefit of directing unwanted reflections away from the capsule, reducing comb-filtering and phase disturbance. The smaller housing advantages the user with greater freedom to place the mic in tighter spots while also reducing particle pressure refraction or what is also known as the vortex around the mic.

Following tradition, a natural presence rise provides added clarity and detail 'on-axis', while the 'off-axis' transition is both smooth and musical. The habitual low-frequency proximity effect provides a warm bottom end that is enhanced as the source is brought closer to the diaphragm.

The UM92's internal low-noise vacuum-tube amplifier features a 'time proven' design that employs a high-mu triode valve that has been selected for its warm sonic characteristics and the natural even-order overtones that are only possible from a tube. For long cable runs, a filament voltage stabilizer is built into the microphone that allows distances of up to 100 meters (328feet) without fluctuation.



Using the UM92

The Gefell UM92 comes equipped with the EA92 deluxe elastic suspension to reduce vibration-borne noise from affecting the microphone. The suspension is secured to the base of the microphone by way of the screw-on, machined housing. This allows the UM92 to be positioned at any angle without worry.

The UM92 comes with its own power supply called the UN920. The UN 920 power supply provides the polarization voltage for the capsule as well as DC voltage for the microphone amplifier. The UN920 features a selectable fuse housing that allows both 110V and 220V operation. A front-panel pattern switch allows the user to remotely select the pattern for figure-8, cardioid, or omnidirectional polar response. All connections are made on the rear panel. A 6-pin Tuchel connector and cable, which powers the microphone, is supplied. Output is balanced 3-pin XLR with pin-2 hot as per the AES standard.

The 92.1S microphone is available in choice of multi-pattern (UM92.1S) or cardioid only (M92). May be custom ordered in a dark bronze finish. The complete system includes the UM92.1S or M92.1S mic, UN920.1 power supply, EA92 elastic suspension, C92.1 cable and W92 windscreen. Comes in it's own hand-crafted wood box.



Interpretation

The Gefell UM92 is a hand-made vacuum tube microphone that is ideally suited for voice, instrument and orchestral work for studio, live recording and broadcast. The design has been optimized for minimal disturbance while yielding excellent sensitivity and low noise.

The result is a wonderful mic that retains the unique hand-made character of its predecessors with all the warmth, smoothness and detail that has made the UM92 a 'living' legend. The UM92 is truly a remarkable microphone!

Microtech Gefell

About Manufacturer

Since its founding by Georg Neumann in 1928, the company has produced high quality, condenser microphones for broadcasting and recording. Many models have used the M7 capsule originally designed by Mr. Neumann in 1949 for the CMV563a. The M7 was responsible for the legendary sound of the Berlin manufactured U47, U48 and M49 microphones. Today, under the technical supervision of Mr. Kuehnast's son, the Company still produces the M7 capsule in exactly the same way Mr. Neumann taught the elder Kuehnast in the 1940's. Hand drilling each hole in the backplate, making the PVC membrane, and even gluing it together by hand is done just as Mr. Neumann specified. The M7 is currently used in the UM 92.1S, UMT800, UMT70S and MT71S Gefell manufactured microphones.

Some of the production equipment which Microtech Gefell GmbH uses for capsule production capitalizes on advanced technology developed by the Soviets before Perestroika. One of the more recently developed microphones, the M300, uses a capsule made of ceramic material molded under high pressure and plated with chromium. This technology was developed in Moscow using advanced computer modeling and simulation techniques. Gefell perfected a capsule manufacturing process unlike any employed in making Western microphones.

The SMS70 series of microphones designed in the early 1970's used a hybrid amplifier with an fet stage. Hybrid technology was not adopted by manufacturers of Western microphones until the late 1980's. Microtech's newest amplifier for the UMT70S series microphones uses surface mount device (SMD) technology.

The company also manufactures a complete line of measurement microphones equivalent to those of Bruel & Kjaer, the Danish manufacturer. These microphones are tested to the highest standards currently used in the West. The manufacturing methods for the nickel membranes and backplate assemblies are highly advanced. Testing each microphone takes a minimum of three months to guarantee performance and stability when it leaves the factory.

Before the Reunification of Germany the company manufactured their studio and broadcast microphones for RFT, a state agency that distributed them to customers in the Eastern Bloc. Most of the microphones went into the broadcast system. Some microphones, like the PM 860, went into public address systems. Virtually every town hall and auditorium in the former Soviet Union has one. About 1985, the Company began developing high powered (30 to 100 Watt) industrial lasers. They still use a laser engraving machine to put the name and serial numbers onto microphones and other finished metal products. During this period, the East German government poured 60 Million Ost Mark into the company allowing them to buy sophisticated equipment and construct a new building.

Specifications

Pattern: Omni, cadriod, figure 8

Response: 40Hz ~ 18 kHz

Sensitivity: 15mV/Pa

Self noise: 17dB-A

Signal to noise: 77dB-A

Maximum SPL: 120dB < 0.5 THD

Dynamic Range: 103dB
