From Apogee Digital
The Apogee ONE is a 2 IN x 2 OUT USB Audio Interface/Microphone for iPad & Mac
Legendary Sound Quality: Why Apogee is the best choice for your studio.
Twice the Power.
- Charges iOS device.
- The only interface that charges iOS devices while in use and can also be battery powered.
Twice the inputs. Record more.
- Simultaneous microphone and instrument recording with internal mic or external mic and instrument input.
Twice the Connectivity. Works with iOS and Mac.
- Direct connection with Lightning iOS devices (iPhone, iPod touch, iPad) and USB connection to Mac.
Twice the Control. Maestro app for iOS and Mac.
- Software control of hardware parameters including input selection and low latency monitoring.
Mac OS
- Computer
- Intel Mac 1.5GHz or faster
- Memory
- 2 GB RAM minimum, 4 GB recommended
- OS
- 10.6.8 or greater
- Connection and power
- Any available USB port on a Mac
USB bus powered; DC power optional
(DC power supply included)
iOS
- iOS version
- 6 or greater
- Connection
- Lightning connector
Power supply or two AA batteries required
(Batteries not included)
iOS device compatibility (Lightning connector)
iPod touch (5th generation), iPod touch (4th generation)
iPhone 5s, iPhone 5c, iPhone 5
iPhone 4s, iPhone 4
iPad (4th generation), iPad (3rd generation), iPad 2
iPad mini
Compatible Software
- Mac
-
- Any Mac Core Audio compatible application
- Recommended apps: Logic, GarageBand, MainStage, Final Cut, Pro Tools, Ableton Live, Digital Performer, Studio One, Cubase, and Nuendo
- iOS
-
- Any iOS Core Audio compatible app. Recommended apps: GarageBand, Auria
Mic Input
0 to 62dB gain
14dBu max input level
Hi-Z
0 to 45 dB gain
Max input level 14 dBu
A/D conversion
- Max input level (+4dBu ref)
- +20dBu
- Max input level (-10dBV ref)
- +6dBV
- Input impedance
- 5KOhm
- Freq resp 20 Hz -20Khz
- > +/-0.2dB (@44.1Khz)
- Rel. THD + N
- -106dB (@ 96Khz)
- Dyn. Range
- 114dB (A-weighted)
D/A conversion
- Max output level (+4dBu ref)
- +20dBu
- Max output level (-10dBV ref)
- +6dBV
- Line output impedance
- 90 Ohm
- Max output level headphones
- 19dBu
HPH output impedance 30 Ohm.
- Freq resp 20Hz -20 Khz
- > +/- 0.05dB (@44.1Khz)
- Rel. THD+N
- -113dB (@96Khz)
- Dyn Range
- 123dB (A-weighted)
Features
First studio quality audio interface and microphone for iPad
New circuitry, mic capsule and upgraded sound quality
Redesigned die cast aluminum chassis
Direct digital connection to iPod touch, iPhone, iPad
Works with GarageBand, MultiTrack, Spotify; Any Core Audio compatible app on iOS
Works with GarageBand, Logic, Pro Tools, Ableton, iTunes; Any Core Audio compatible app on Mac
Low latency monitoring, complete input/output control with Apogee’s Maestro software (iOS & Mac)
DC power supplies charge to iPod touch, iPhone or iPad
Optional battery operation for remote recording on iPad (2 AA batteries not included)
USB 2.0 audio with 24-bit/96kHz A/D and D/A conversion
Built-in omnidirectional condenser microphone (mic stand adapter included)
- 2 Analog Inputs
-
- XLR microphone and 1/4” instrument connector on breakout cable
- Built-in omnidirectional condenser microphone
- 2 simultaneous inputs (instrument + built-in or external mic)
- Mic preamp with up to 62dB of gain
- 2 Analog Outputs
-
- 1 1/8” stereo output for headphones or powered speakers
- A/D and D/A conversion
- 24 bit/96kHz
Legendary Apogee sound quality
Designed in California – Made in the U.S.A.
In the box
ONE
- Breakout cable with
- 1 XLR Mic input
1 1/4” Instrument input
Microphone stand clip
USB cable
Lightning iOS cable
Universal power supply with NA, EU, UK, AU, JP
QuickStart guide
Free 3-Year Warranty
