SPL Transducer  From SPL

Analog Speaker and Miking Simulator

SPL

Manufacturer's Description from SPL


The SPL Transducer is an analog cabinet and miking simulator for guitar amplifiers which was designed in a cooperative developmental effort with German guitar amp specialists of Tonehunter.

In studio and on stage the Transducer replaces the guitar speaker cabinet and microphone(s) so that the time and resource-intensive microphone processing of this loud sonic source is no longer necessary. In addition the Transducer offers much more sonic flexibility and variety than a single mike and cabinet setup because it allows for varied speaker and mike simulations while allowing to retain accustomed features of individual setups (such as the ability to vary level-dependent loudspeaker characteristics and microphone distances).

Via headphones you can play inaudibly while the Transducer delivers authentic sounds even of the finest nuances of your guitar amp. Pure, high-quality analog design produces the same load like a cabinet and guarantees direct response with latency-free processing.

You want to record your fully torqued tube amp in a hotel at night? You’ll stay. Everything goes in studio and home sessions, everwhere, everytime – and without a sound booth.

On stage all problems with loud cabs and complex mikings are avoided. The artist can play with in-ear-monitoring at moderate levels, and a perfect signal in recording quality is provided for the live mix!

Features:

  • Authentic sound qualities and real time response for the guitar player in contrast to digital simulations with latencies in processing
  • Independence from volume levels during performances or recording sessions
  • Independence from room acoustics in recordings
  • Provides for a live signal in recording quality without crosstalk from miking Great space and weight reduction in transport
SPL

About Manufacturer

Sound Performance Labs! Full Range of Analog, Tube, and Digital rack gear with an innovative twist. With their most famous transient designer product, SPL has quickly become a household name in both the recording and live sound arenas.

Specifications

Outputs

  • Speaker Thru:1/4" Jack connection
  • Pre Simulation Out:1/4" Jack connection
  • Impedanceca. 1 kOhm

Mic Level Output

  • XLR, electronically balanced
  • Impedance unbalanced:ca. 600 Ohms
  • Impedance balanced:ca. 1,2 kOhms
  • Max. Output Level:+6 dBu
  • Signal to Noise Rati:o-100 dBu (A weighted)

Line Output 1

  • XLR, electronically balanced
  • Impedance: unbalancedca. 600 Ohms
  • Impedance: balancedca. 1,2 kOhms
  • Max. Output Level:+21,5 dBu
  • Signal to Noise Ratio:-94 dBu (A weighted)

Line Output 2

  • XLR and 1/4" TRS connection, electronically balanced
  • Impedance unbalanced:ca. 600 Ohms
  • Impedance balanced: ca. 1,2 kOhms
  • Max. Output Level:+21,5 dBu
  • Signal to Noise Ratio:-94 dBu (A weighted)

Power Supply

Selectable Line Voltages:

  • 115 V AC, 60 Hz/ 230 V AC, 50 Hz

Power Consumption:

  • 5,2 VA

Fuses:

  • 110 – 120 V AC: 400 mA slow blow
  • 220 – 240 V AC: 200 mA slow blow

Power Connector:

  • Standard 3-prong IEC connector

Dimensions & Weight

Height x Width x Depth:

  • 88,2 mm x 482,6 mm x 270 mm/ ca. 3,4" x 19" x 10,6"

Weight:

  • 4,8 kg/10,58 lbs

Downloads

Action

Name

Description

1091-SPL_Transducer-1272880eec4-5a.pdf

SPL Transducer Manual PDF
