Phoenix Audio DRS-1R 500 Series Preamp
Phoenix Audio DRS-1R 500 Series Preamp Phoenix Audio DRS-1R 500 Series Preamp Phoenix Audio DRS-1R 500 Series Preamp

The infamous DRS-1 mic pre condensed into a compact 500 series unit.

IN STOCK!
Ships immediately after order processed!

Want to Try Before you Buy?

To Setup a Free Trial in your studio,
Call us Now: 888-528-9703

Phoenix Audio DRS-1R 500 Series Module Preamp

  • Products used:
    • Phoenix Audio DRS-1R 500 Series Preamp
More text

The DRS1r from Phoenix Audio UK is a 500 series style module mic pre based on their incredible DRS-1 and DRS-8 microphone preamplifiers. At AES 2011 we were able to talk to Robin at Phoenix about th...

Less text

The DRS1r from Phoenix Audio UK is a 500 series style module mic pre based on their incredible DRS-1 and DRS-8 microphone preamplifiers. At AES 2011 we were able to talk to Robin at Phoenix about these fantastic sounding preamps. Not only is the sound quality superb, but you can get great sounding clean tones, or drive the output gain knob to get more saturated tones full of color. The DRS 1R works great in lunch boxes with other 500 series preamps and there are no power issues. Watch SoundPure's other demos on the DRS-8 where we got to test it on a variety of applications in a studio environment. Call for more information on the DRS-1r from Phoenix Audio UK. 919.682.5552.

Description:

The Phoenix Audio DRS1R/500 is a mono pre amp and DI for the API 500 series, it was designed to be identical in terms of features and sonics as the ever popular DRS1 but in a new format. The unit runs at 24v thanks due to the special power supply built into the unit so it offers no sonic sacrifices whilst still maintaining a very low current use needed for the API format and is well within its API VPR limits.

Specs:

Specifications

  • Class A (DSOP2) Output specs. Frequency response: 20Hz to 20kHz +- 0.5dB, Maximum Output = +26dBu @ 1kHz, Noise = -90dB @ 20Hz to 20kHz.
  • Output connections: XLR's on rear panel of API rack
  • Phoenix Audio's unique Class A, transformerless, True balanced Mic input stage.
  • Microphone input: XLR's  Rear Panels of API rack
  • Gain Range (Mic input): -30 to -70 in 5dB steps With 10dB more available on the output fader.
  • Gain reduction: -30dB push-button Mic/Line switch (Mic input)
  • High Input Impedance DI: Mono 1/4" Jack on front panel
  • Gain Meter: LED Metering. (Green = -2dbu, +4dbu & 0dBu, Yellow = +13dbu Red= +16dBu)
  • Phantom Power: Switchable phantom on Push-button Switch
  • High Pass Filter: on Push-button Switch, 120hz 6db per octave
  • Phase Reverse: on Push-button Switch
  • Mute : on Push-button Switch
  • Frequency Response Mic Input Stage: -0.4dB @ 40Hz, -0.3dB @ 25kHz
  • Frequency Response: DI Input Stage: -0.3dB @ 40Hz, - 0.5dB @ 25kHz
  • Typical Headroom: +24dB on Mic-Pre stage
  • DI Stage gain: Maximum of 20dB
